  • PRV Audio 12MB1500FT Forte Series 12" Midbass Speaker 8 Ohm

NEW PRV Audio 12MB1500FT Forte Series 12" Midbass Speaker 8 Ohm

PRV Audio
Part #294-2870

NEW PRV Audio 12MB1500FT Forte Series 12" Midbass Speaker 8 Ohm

PRV Audio
Part #294-2870
Model: 12MB1500FT

The PRV Audio 12MB1500FT is a high-performance 12-inch midbass loudspeaker engineered for professional audio applications requiring robust midbass reproduction. Part of PRV's Forte Series, it delivers exceptional linear response down to 75 Hz, making it ideal for 2-way cabinet systems that demand strong BL magnet force and impactful midbass punch.

Key Features
  • High BL factor and Xmax for outstanding low-frequency output
  • Rated at 1500 watts RMS continuous program power
  • Sensitivity of 98.5 dB, capable of generating substantial output
  • 3.5" inside/outside CCAW voice coil wound on a fiberglass former for high-temperature performance
  • Heavy-duty spider with M-roll treated cloth surround, designed for high-excursion applications
  • Double silicon spider system ensures excellent control during large excursions
  • Strong ferrite magnetic structure with dual forced cooling system for efficient voice coil ventilation
Similar items that may interest you:
See all items in Pro Woofers, Subwoofers & Midrange Speakers
NEW $164.91
+ FREE SHIPPING
MSRP: $206.14
Save $41.23 (20%)
Bulk Pricing

Back-Ordered

Expected back in stock any day
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 12MB1500FT Forte Series 12" Midbass Speaker 8 Ohm

PRV Audio 12MB1500FT Forte Series 12" Midbass Speaker 8 Ohm

The PRV 12MB1500FT delivers a highly linear response, smoothly extending down to 75 Hz, making it an ideal choice for 2-way cabinet systems needing strong BL force and impactful midbass. It’s a powerful new addition to the Forte Series, focused on delivering higher power handling and reduced distortion in the mid to low midbass range.

  • High BL factor and Xmax for outstanding low-frequency output
  • Rated at 1500 watts RMS Continuous Program Power
  • 98.5 dB sensitivity, which makes it capable of generating a lot of output!
  • 3.5″ Inside/Out CCAW voice coil wound on fiberglass former for hi-temp performance, 8 Ohm

Supporting the cone is a heavy-duty spider with an M-roll treated cloth surround, specifically designed for high-excursion applications to handle short bursts of excessive power without sustaining damage. A double silicon spider system further enhances control during large excursions, allowing the driver to achieve up to 1.50 inches of peak-to-peak movement while maintaining performance and reliability.

A robust 25 mm ferrite magnetic structure ensures dynamic and precise performance, while the unique 3.5-inch inside/outside voice coil design delivers exceptionally high power handling of 1500 watts RMS. Enhanced by a dual forced cooling system, this design ensures highly efficient voice coil ventilation, minimizing power compression and maintaining consistent performance even during demanding audio applications.

Specifications

  • Nominal Diameter: 12″ (305 mm)
  • Nominal impedance: 8 Ohm
  • Nominal Power Handling:* 750 Watts
  • Continuous Program Power (RMS):** 1500 Watts
  • Max Peak Power:*** 3000 Watts
  • Sensitivity 2.83V at 1m: 98.5 dB
  • Recommended Hi Pass Crossover: 90 Hz
    For Full Power Handling — 12db Per Octave Crossover
  • Frequency Response: 75 – 5,000 Hz
  • Voice Coil Diameter: 3.5″ (89 mm)
  • Voice Coil Wire: CCAW
  • Voice Coil Winding Depth: 17.0 mm
  • Former Material: Glass Fiber
  • Magnetic Gap Depth: 10.0 mm
  • Frame Material: Die Cast Aluminum
  • Overall Diameter: 12.40” (315 mm)
  • Front Mount Baffle Cutout: 11.18” (284 mm)
  • Mounting Depth: 5.24”(133 mm)
  • Overall Depth: 5.87”(149 mm)
  • Net Weight: 16.32 Lbs (7.4 kg)

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

Explore the Forte Series

6MB550FT 6.5" Midbass Speaker 8 Ohm

6MB550FT-4 6.5" Midbass Speaker 4 Ohm

8MB700FT 8" Midbass Speaker 8 Ohm

8MB700FT-NDY 8" Neodymium Midbass Speaker 8 Ohm

8MB700FT-NDY-4 8" Neodymium Midbass Speaker 4 Ohm

10MB800FT 10" Midbass Speaker 8 Ohm

10MB1000FT 10" Midbass Speaker 8 Ohm

12MB1000FT 12" Midbass Speaker 8 Ohm

12MB1000FT-4 12" Midbass Speaker 4 Ohm

12MB1500FT 12" Midbass Speaker 8 Ohm

Product Details

BrandPRV Audio
Model12MB1500FT
Part Number294-2870
UPC810075522761
Unit of MeasureEach
Weight17.55

Product Specifications

Nominal Diameter12"
Power Handling (RMS)1500 Watts
Power Handling (MAX)3000 Watts
Impedance8Ω
Frequency Response75 to 5,000Hz
Sensitivity98.5dB 2.83V/1m
Voice Coil Diameter3.5"

Thiele-Small Parameters

Resonant Frequency (Fs)57.2Hz
DC Resistance (Re)5.2Ω
Voice Coil Inductance (Le)0.963mH
Mechanical Q (Qms)10.87
Electromagnetic Q (Qes)0.37
Total Q (Qts)0.36
Compliance Equivalent Volume (Vas)2.2ft³
Mechanical Compliance of Suspension (Cms)0.13mm/N
BL Product (BL)17.27T·m
Diaphragm Mass Inc. Airload (Mms)59.32g
Maximum Linear Excursion (Xmax)6mm
Surface Area of Cone (Sd)585cm²

Materials of Construction

Voice Coil Wire MaterialCCA
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum

Mounting Information

Overall Outside Diameter12.40"
Baffle Cutout Diameter11.18"
Depth5.24"
# Mounting Holes8
