PRV Audio 10MB1000FT Forte Series 10" Midbass Speaker 8 Ohm

PRV Audio
Part #294-3412

PRV Audio 10MB1000FT Forte Series 10" Midbass Speaker 8 Ohm

PRV Audio
Part #294-3412
Model: 10MB1000FT

The PRV Audio 10MB1000FT is a 10" midbass loudspeaker designed for smooth, powerful response in professional audio systems. Built for high-output use, it offers strong performance without compromising clarity. Its robust design supports demanding applications with flexibility.

Key Features
  • 1000 watts continuous program power rating makes the high acoustical output
  • 3″ Inside/Out copper clad aluminum wire on glass fiber former for hi-temp performance
  • Rigid cast aluminum frame can withstand the use and abuse of pro and car audio
  • Natural paper cone and double-roll surround for smooth response
  • Ventilated voice coil gap reduces power compression
Your Price: $169.91
+ FREE SHIPPING
MSRP: $212.39
Save $42.48 (20%)
Bulk Pricing
Order in the next 0 hr 57 min to ship today. Details

8In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 10MB1000FT Forte Series 10" Midbass Speaker 8 Ohm

PRV Audio 10MB1000FT Forte Series 10" Midbass Speaker 8 Ohm

Combining high output with low distortion midbass performance, PRV Audio’s 10MB1000FT 10″ professional midbass loudspeaker is an ideal option for high-powered sound reinforcement systems, stage monitors, and high SPL PROAudioOnWheels builds.

A strong addition to the Forte Series, it focuses on increased power handling and reduced distortion in the mid to low midbass range. The 10MB1000FT is a durable 10″ midbass driver that delivers impactful punch and vocal clarity at high SPL with extended response. Optimized for compact enclosures, it’s designed to perform with authority in the low midbass region while offering smooth vocal output and usable response up to 7,000 Hz, making it a great fit for larger 2-way and 3-way systems.

  • 3″ inside/out copper-clad aluminum wire wound on a glass fiber former for high temperature performance, 8 ohms
  • Ventilated voice coil gap helps minimize power compression
  • High Xmax delivers greater midbass output
  • 1000 watts continuous program power rating enables high acoustic performance
  • Built to perform—engineered to withstand heavy use and demanding conditions

To achieve superior fidelity, the special composite cone is made from non-pressed paper to minimize break-up, resulting in a smooth frequency response and low moving mass that improves speaker efficiency.

With a high sensitivity rating of 97.5 dB 1W/1M, it’s capable of delivering substantial output. This 10″ is an excellent midbass choice for professional audio systems or high SPL car audio setups where extremely high output is needed.

The voice coil is wound on a 3″ glass fiber former with copper-clad aluminum wire, keeping weight low for fast transient response. Designed with 11 mm of winding depth, this inside/outside coil construction ensures outstanding thermal and mechanical durability.

Specifications

  • Nominal Diameter: 10″ (254 mm)
  • Nominal impedance: 8 Ohm
  • Nominal Power Handling:* 500 Watts
  • Continuous Program Power (RMS):** 1000 Watts
  • Max Peak Power:*** 2000 Watts
  • Sensitivity 2.83V at 1m: 97.5 dB
  • Recommended Hi Pass Crossover: 120 Hz
    For Full Power Handling — 12db Per Octave Crossover
  • Frequency Response: 75 – 7,000 Hz
  • Voice Coil Diameter: 3″ (75 mm)
  • Voice Coil Wire: CCAW
  • Voice Coil Winding Depth: 16.5 mm
  • Former Material: Fiberglass
  • Magnetic Gap Depth: 9.5 mm
  • Frame Material: Die Cast Aluminum
  • Overall Diameter: 10.25” (260.5 mm)
  • Front Mount Baffle Cutout: 9.01” (229 mm)
  • Mounting Depth: 4.09” (104 mm)
  • Overall Depth: 4.68” (119 mm)
  • Net Weight: 11.01 Lbs (5.0 kg)

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

Explore the Forte Series

6MB550FT 6.5" Midbass Speaker 8 Ohm

6MB550FT-4 6.5" Midbass Speaker 4 Ohm

8MB700FT 8" Midbass Speaker 8 Ohm

8MB700FT-NDY 8" Neodymium Midbass Speaker 8 Ohm

8MB700FT-NDY-4 8" Neodymium Midbass Speaker 4 Ohm

10MB800FT 10" Midbass Speaker 8 Ohm

10MB1000FT 10" Midbass Speaker 8 Ohm

12MB1000FT 12" Midbass Speaker 8 Ohm

12MB1000FT-4 12" Midbass Speaker 4 Ohm

12MB1500FT 12" Midbass Speaker 8 Ohm

Product Details

BrandPRV Audio
Model10MB1000FT
Part Number294-3412
UPC810075520972
Unit of MeasureEach
Weight16.55

Product Specifications

Nominal Diameter10"
Power Handling (RMS)500 Watts
Power Handling (MAX)1000 Watts
Impedance8Ω
Frequency Response75 to 7,000Hz
Sensitivity97.5dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)75Hz
DC Resistance (Re)5.3Ω
Voice Coil Inductance (Le)0.26mH
Mechanical Q (Qms)12.41
Electromagnetic Q (Qes)0.33
Total Q (Qts)0.32
Compliance Equivalent Volume (Vas)1.14ft³
Mechanical Compliance of Suspension (Cms)0.16mm/N
BL Product (BL)14.49T·m
Diaphragm Mass Inc. Airload (Mms)28.1g
Maximum Linear Excursion (Xmax)5.87mm
Surface Area of Cone (Sd)380cm²

Materials of Construction

Voice Coil Wire MaterialCCA
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.25"
Baffle Cutout Diameter9.01"
Depth4.4"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume198.5ft³
Sealed F30.175Hz
Vented Volume118.1ft³
Vented F30.418Hz
