Model: 15MC500

The Beyma 15MC500 is a 15" subwoofer driver designed for professional audio systems requiring robust performance and high efficiency. Its advanced Maltcross cooling technology and durable construction make it well-suited for 2-way or 3-way PA systems and line arrays in demanding environments.

Key Features
  • Maltcross cooling system reduces power compression​
  • Aluminum demodulating ring minimizes distortion​
  • ±8 mm Xmax allows for extended linear excursion​
  • Weatherproof cone treatment on both sides for increased durability​
  • 40 mm peak-to-peak excursion before damage ensures mechanical reliability​
  • Optimized for 2-way or 3-way PA systems and line arrays​
  • 2.5" copper wire voice coil enhances thermal stability​
Similar items that may interest you:
See all items in Subwoofer Drivers
NEW $217.50
+ FREE SHIPPING
MSRP: $290.00
Save $72.50 (25%)
Bulk Pricing
Order in the next 0 hr 26 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Beyma 15MC500 MC Series 15" Subwoofer 8 Ohm

12MC700Nd MC Series 12" Neo Subwoofer 8 Ohm

The 15MC500's 500 W AES power handling and 98 dB sensitivity enable it to deliver clear and dynamic sound output, making it suitable for demanding audio applications. Its 2.5" copper wire voice coil enhances thermal stability, contributing to consistent performance over time. The Maltcross cooling system effectively dissipates heat, reducing power compression and maintaining consistent output during prolonged use. An aluminum demodulating ring is incorporated to minimize distortion, resulting in cleaner sound reproduction. The driver features an Xmax of ±8 mm, allowing for extended linear cone movement and deeper bass response without distortion. Its weatherproof cone, treated on both sides, enhances durability and resistance to environmental factors, making it suitable for both indoor and outdoor applications. With a peak-to-peak excursion before damage of 40 mm, the 15MC500 can withstand significant mechanical stress, ensuring longevity even under high-demand conditions. Optimized for use in 2-way or 3-way PA systems and line arrays, this transducer offers versatility and high performance for professional audio setups.​

At Beyma, the challenge of heat dissipation is met with a clear objective: ensuring our speakers consistently deliver optimal performance within the system, maximizing total sound pressure level (SPL) and maintaining stability.​

It's widely recognized that a system's overall SPL decreases over time due to power compression effects in the speakers. Typically, larger voice coil diameters correlate with higher power capacity; however, this also necessitates bigger motor structures to achieve high total output from the transducer.​

Beyma's Maltcross cooling technology presents multiple solutions to achieve this goal. It enables the woofer to handle higher power levels with a given coil diameter, allowing for designs with smaller coils and motor structures. This reduction in size decreases weight, increases sensitivity, and maintains adequate power handling for specific applications, resulting in a total SPL comparable to that of drivers with larger motor structures.

Maltcross technology incorporates a forced convection circuit within the driver's core, effectively lowering the coil's operating temperature. Additionally, it functions as a demodulation ring, linearizing the transducer's inductance.

Product Details

BrandBeyma
Model15MC500
Part Number253-016
UPC8435469043688
Unit of MeasureEach
Weight15.9

Product Specifications

Nominal Diameter15"
Bolt Circle Diameter14.6
Power Handling (RMS)500 Watts
Power Handling (MAX)1000 Watts
Impedance8Ω
Frequency Response50 to 4,000Hz
Sensitivity98dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)46Hz
DC Resistance (Re)5.6Ω
Voice Coil Inductance (Le)1.1mH
Mechanical Q (Qms)7.8
Electromagnetic Q (Qes)0.47
Total Q (Qts)0.45
Compliance Equivalent Volume (Vas)4.73ft³
Mechanical Compliance of Suspension (Cms)122mm/N
BL Product (BL)18.3T·m
Diaphragm Mass Inc. Airload (Mms)0.098g
Maximum Linear Excursion (Xmax)8mm
Surface Area of Cone (Sd)0.088cm²

Materials of Construction

Cone MaterialPaper-Treated Paper
Voice Coil Wire MaterialCopper
Basket / Frame MaterialCast Aluminum

Mounting Information

Overall Outside Diameter15.3"
Baffle Cutout Diameter13.8"
Depth6.8"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.607ft³
Sealed F388.55Hz
Vented Volume5.113ft³
Vented F344.41Hz
