PRV Audio 8MR600X-NDY X Series 8" Neodymium Midrange Speaker 8 Ohm

PRV Audio
Part #294-3538

PRV Audio 8MR600X-NDY X Series 8" Neodymium Midrange Speaker 8 Ohm

PRV Audio
Part #294-3538
Model: 8MR600X-NDY

PRV's X Series is committed to offering extreme midrange performance and high power capability in both the pro and competitive car audio worlds. The 8MR600X-NDY is a high-performance 8" neodymium midrange speaker engineered for exceptional audio clarity and efficiency. With a robust 600W RMS power handling, it delivers powerful sound reproduction suitable for demanding audio applications.

Key Features
  • 2″ dual-layer CCAW voice coil wound on a Kapton former, 8 Ohm
  • Built with premium components for long-lasting performance under intense use
  • Low inductance and extended frequency response with wide directivity
  • 600W RMS continuous program power rating for high acoustic output
  • Ideal for compact full-range applications requiring powerful sound
  • Delivers detailed vocal response and pristine instrument reproduction
Your Price: $189.91
+ FREE SHIPPING
MSRP: $237.39
Save $47.48 (20%)
Bulk Pricing
Order in the next 1 hr 3 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 8MR600X-NDY X Series 8" Neodymium Midrange Speaker 8 Ohm

8MR600X-NDY 8" Neodymium Midrange Speaker

The PRV Audio 8MR600X-NDY is built for extreme midrange performance. Designed as a class-leading speaker in the pro audio realm, it delivers a high output sensitivity of 98.5 dB while weighing only 5 pounds. Optimized for professional audio, musical instrument applications, and large car audio competition systems, it offers exceptional power and efficiency.

Its powerful halo neodymium magnet assembly ensures high flux concentration for maximum performance. The advanced magnetic structure enhances thermal connection and heat dissipation, increasing power handling while reducing power compression. This optimized power-to-weight ratio makes it a top choice for demanding audio setups.

Delivering high output with minimal distortion, this midrange speaker fills the crucial midrange frequencies in any high-output sound system. A standout addition to the X-Series, it offers precision, power, and reliability for the most demanding applications.

  • 2″ dual-layer CCAW voice coil wound on a Kapton former, 8 Ohm
  • Built with premium components for long-lasting performance under intense use
  • Low inductance and extended frequency response with wide directivity
  • 600W RMS continuous program power rating for high acoustic output
  • Ideal for compact full-range applications requiring powerful sound
  • Delivers detailed vocal response and pristine instrument reproduction

A coated woven surround maintains smooth, precise geometry even during intense play. The lightweight cone delivers excellent linear response, enhancing performance with a wide frequency bandwidth and high output levels from 3,200 to 10,000 Hz.

This design makes the 8MR600X-NDY an outstanding choice for high-quality two-way or three-way sound systems. Its combination of clarity, efficiency, and durability ensures superior audio reproduction in demanding applications.

The PRV Audio 8MR600X-NDY is the ultimate 8″ midrange door speaker for extreme car audio enthusiasts. Capable of handling up to 600 watts RMS, it delivers powerful performance when paired with a properly tuned PRV DSP and a 125 Hz, 18 dB/octave high-pass filter.

Its high-energy rare-earth neodymium motor, combined with premium materials, enhances sensitivity and power handling. Designed for audiophiles and custom builders, this speaker captures the finest audio details with precision and clarity. Built for high-performance car audio systems, it offers unmatched output and responsiveness.

General Specifications

  • Nominal Diameter: 8″ (203 mm)
  • Nominal impedance: 4 Ohm
  • Nominal Power Handling*: 300 Watts
  • Continuous Program Power (RMS)**: 600 Watts
  • Max Peak Power***: 1200 Watts
  • Sensitivity 2.83V at 1m: 98.5 dB
  • Recommended Hi Pass Crossover For Full Power Handling: 145 Hz 12db Per Octave Crossover
  • Frequency Response: 95 – 10,500 Hz
  • Voice Coil Diameter: 2″ (50 mm)
  • Voice Coil Wire: CCAW
  • Voice Coil Winding Depth: 11 mm
  • Former Material: Kapton
  • Magnetic Gap Depth: 7 mm
  • Frame Material: Die Cast Aluminum
  • Overall Diameter: 8.11” (206 mm)
  • Front Mount Baffle Cutout: 7.16” (182 mm)
  • Mounting Depth: 3.81” (96.7 mm)
  • Overall Depth: 3.81” (96.7 mm)
  • Net Weight: 5 lbs. (2.26 kg)

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

Explore the PRV X Series

6MR600X-NDY 6.5" Neodymium Midrange Speaker 8 Ohm

6MR600X-NDY-4 6.5" Neodymium Midrange Speaker 4 Ohm

8MR600X 8" Ferrite Midrange Speaker 8 Ohm

8MR600X-NDY 8" Neodymium Midrange Speaker 8 Ohm

8MR600X-4 8" Ferrite Midrange Speaker 4 Ohm

10MR1200X 10" Midrange Speaker 8 Ohm

12MR1200X 12" Midrange Speaker 8 Ohm

12MR2000X v2 12" Midrange Speaker 8 Ohm

12MR2000X-NDY 12" Neodymium Midrange Speaker 8 Ohm

Product Details

BrandPRV Audio
Model8MR600X-NDY
Part Number294-3538
UPC810075525519
Unit of MeasureEach
Weight25.3

Product Specifications

Nominal Diameter8"
Power Handling (RMS)600 Watts
Power Handling (MAX)1200 Watts
Impedance8Ω
Frequency Response95 to 10,000Hz
Sensitivity98.5dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)87.6Hz
DC Resistance (Re)6.3Ω
Voice Coil Inductance (Le)0.03mH
Mechanical Q (Qms)17.78
Electromagnetic Q (Qes)0.3
Total Q (Qts)0.29
Compliance Equivalent Volume (Vas)0.444ft³
Mechanical Compliance of Suspension (Cms)0.167mm/N
BL Product (BL)15.17T·m
Diaphragm Mass Inc. Airload (Mms)19.73g
Maximum Linear Excursion (Xmax)3.75mm
Surface Area of Cone (Sd)232cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter8.11"
Baffle Cutout Diameter7.16"
Depth3.45"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.0558ft³
Sealed F3252.6Hz
Vented Volume0.129ft³
Vented F3153.7Hz
