PRV Audio 6MR600X-NDY-4 X Series 6.5" Neodymium Midrange Speaker 4 Ohm

PRV Audio
Part #294-3408

PRV Audio 6MR600X-NDY-4 X Series 6.5" Neodymium Midrange Speaker 4 Ohm

PRV Audio
Part #294-3408
Model: 6MR600X-NDY-4

PRV's X Series is committed to offering extreme midrange performance and high power capability in both the pro and competitive car audio worlds. The 6MR600X-NDY-4 is a high-performance 6.5" neodymium midrange speaker engineered for exceptional audio clarity and efficiency. With a robust 600W RMS power handling, it delivers powerful sound reproduction suitable for demanding audio applications.

Key Features
  • 2″ Inside/Out voice coil on a high-temperature former, 4 Ohm
  • 600 Watts RMS power handling with 97.5 dB sensitivity for high output
  • Low inductance and extended frequency response with wide directivity
  • New-generation neodymium magnet structure for enhanced performance
  • Ideal for compact full-range applications requiring high acoustic output, also available in 8 Ohm
  • Delivers coaxial performance from a single speaker
Your Price: $179.91
+ FREE SHIPPING
MSRP: $224.89
Save $44.98 (20%)
Bulk Pricing

Out of Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 6MR600X-NDY-4 X Series 6.5" Neodymium Midrange Speaker 4 Ohm

6MR600X-NDY-4 6" Neodymium Midrange Speaker

The PRV Audio 6MR600X-NDY-4 is built for X-treme midrange performance.

Designed with cutting-edge advancements, this speaker pushes the limits of PRV Audio’s engineering. Crafted with top-tier components, it delivers powerful, long-lasting play, even under intense conditions. Its durable construction ensures reliability for high-performance applications. This midrange loudspeaker is the perfect balance of strength, efficiency, and premium sound quality.

  • 2″ Inside/Out voice coil on a high-temperature former, 4 Ohm
  • 600 Watts RMS power handling with 97.5 dB sensitivity for high output
  • Low inductance and extended frequency response with wide directivity
  • New-generation neodymium magnet structure for enhanced performance
  • Ideal for compact full-range applications requiring high acoustic output, also available in 8 Ohm
  • Delivers coaxial performance from a single speaker

This high-performance midrange loudspeaker delivers output comparable to a compression driver in the upper midrange. The naturally damped paper cone extends frequencies up to 13,000 Hz for exceptional clarity.

With its extreme output capability, this speaker eliminates the need for a separate high-frequency compression driver. It provides true 2-way coaxial performance from a single unit, making it an efficient solution for high-output systems. Designed for power and precision, it delivers unmatched midrange clarity with wide frequency coverage.

The high-energy neodymium motor, paired with premium materials, enhances sensitivity and power handling for superior audio detail. Designed to meet the demands of audiophiles and custom builders, it delivers precision and clarity in every performance.

With an extended frequency bandwidth and powerful output between 3,000 to 10,000 Hz, this midrange speaker redefines performance. Its remarkable 600 Watts RMS power handling ensures high-output capability for even the most demanding systems. Eliminating the need for a compression driver, it offers a streamlined solution for high-fidelity sound in car and motorcycle audio setups.

This midrange features a 2” double-layered copper-clad aluminum wire voice coil with a symmetrical inductance profile. Its 11 mm winding length enhances heat dissipation and maintains high sensitivity, even under high power, while minimizing distortion.

Engineered for reliability, every aspect of this speaker is built for consistent high output levels. It performs flawlessly even at its limits, ensuring clear and powerful sound reproduction. Delivering high-fidelity audio with minimal distortion, it provides an optimal listening experience for demanding applications.

General Specifications

  • Nominal Diameter: 6″ (152 mm)
  • Nominal impedance: 4 Ohm
  • Nominal Power Handling*: 300 Watts
  • Continuous Program Power (RMS)**: 600 Watts
  • Max Peak Power***: 1200 Watts
  • Sensitivity 2.83V at 1m: 97.5 dB
  • Recommended Hi Pass Crossover For Full Power Handling: 160 Hz 12db Per Octave Crossover
  • Frequency Response: 90 – 13,000 Hz
  • Voice Coil Diameter: 2″ (50 mm)
  • Voice Coil Wire: CCAW
  • Voice Coil Winding Depth: 11.0 mm
  • Former Material: Kapton
  • Magnetic Gap Depth: 8.0 mm
  • Frame Material: Die Cast Aluminum
  • Overall Diameter: 6.48” (164.5 mm)
  • Front Mount Baffle Cutout: 5.63” (143 mm)
  • Mounting Depth: 3.09” (78.5 mm)
  • Overall Depth: 3.43” (87 mm)
  • Net Weight: 4.63 lbs. (2.1 kg)

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

Explore the PRV X Series

6MR600X-NDY 6.5" Neodymium Midrange Speaker 8 Ohm

6MR600X-NDY-4 6.5" Neodymium Midrange Speaker 4 Ohm

8MR600X 8" Ferrite Midrange Speaker 8 Ohm

8MR600X-NDY 8" Neodymium Midrange Speaker 8 Ohm

8MR600X-4 8" Ferrite Midrange Speaker 4 Ohm

10MR1200X 10" Midrange Speaker 8 Ohm

12MR1200X 12" Midrange Speaker 8 Ohm

12MR2000X v2 12" Midrange Speaker 8 Ohm

12MR2000X-NDY 12" Neodymium Midrange Speaker 8 Ohm

Product Details

BrandPRV Audio
Model6MR600X-NDY-4
Part Number294-3408
UPC810075520859
Unit of MeasureEach
Weight5.05

Product Specifications

Nominal Diameter6"
Power Handling (RMS)600 Watts
Power Handling (MAX)1200 Watts
Impedance4Ω
Frequency Response90 to 13,000Hz
Sensitivity97.5dB 2.83V/1m
Voice Coil Diameter2"

Thiele-Small Parameters

Resonant Frequency (Fs)95.2Hz
DC Resistance (Re)3.4Ω
Voice Coil Inductance (Le)0.005mH
Mechanical Q (Qms)12.54
Electromagnetic Q (Qes)0.2
Total Q (Qts)0.19
Compliance Equivalent Volume (Vas)0.185ft³
Mechanical Compliance of Suspension (Cms)0.18mm/N
BL Product (BL)12.66T·m
Diaphragm Mass Inc. Airload (Mms)15.45g
Maximum Linear Excursion (Xmax)3.5mm
Surface Area of Cone (Sd)143cm²

Materials of Construction

Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter6.48"
Baffle Cutout Diameter5.63"
Depth3.09"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume411.2ft³
Sealed F30.0095Hz
Vented Volume264.9ft³
Vented F30.0198Hz
