NEW PRV Audio 12MR2000X v2 X Series 12" Midrange Speaker 8 Ohm

PRV Audio
Part #294-3405

NEW PRV Audio 12MR2000X v2 X Series 12" Midrange Speaker 8 Ohm

PRV Audio
Part #294-3405
Model: 12MR2000X v2

PRV's X Series is committed to offering extreme midrange performance and high power capability in both the pro and competitive car audio worlds. The 12MR2000X v2 is a 12″ midrange loudspeaker engineered for high-efficiency and extreme output capability. Designed for the largest SPL systems, it delivers detailed vocal reproduction and high-fidelity response, making it ideal for professional audio applications.

Key Features
  • Handles up to 2,000 Watts RMS with 100 dB sensitivity for exceptional output capability
  • 4″ diameter voice coil wound on a glass fiber former ensures reliable high-temperature performance
  • 6.60 mm Xmax allows excellent control to deliver high-impact midbass
  • Extensive venting keeps the voice coil cool, improving reliability during intense operation
  • Composite cone built with non-pressed paper reduces break-up for smooth sound
  • Double roll suspension design allows for strong response even at high excursion
  • Sturdy, reinforced cast-aluminum frame provides durability in demanding applications.
NEW $229.91
+ FREE SHIPPING
MSRP: $287.39
Save $57.48 (20%)
Bulk Pricing
Order in the next 2 hr 15 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 12MR2000X v2 X Series 12" Midrange Speaker 8 Ohm

12MR2000X v2 12" Midrange Speaker 8 Ohm

Engineered for high efficiency and massive output, the PRV Audio 12MR2000X v2 12″ midrange driver is built to dominate the midbass and vocal range in the most demanding SPL systems. Its fully ventilated 4″ voice coil, wound on a heat-resistant Kapton former, allows it to manage an impressive 2,000 watts RMS while minimizing power compression.

As part of the X Series, it’s purpose-built for extreme midrange performance, offering high output, robust power handling, and a smooth, detailed vocal response.

  • Handles 2,000 watts RMS with 100 dB sensitivity for exceptional output
  • 6.60 mm xmax provides precise control and powerful, punchy midbass
  • Reproduces vocals with clarity and delivers high-fidelity midrange response
  • Performs reliably in compact enclosures, ideal for SPL-focused designs
  • Fully ventilated 4″ voice coil stays cool under extreme conditions for improved durability and consistent performance

PRV Audio’s 12MR2000X is an ideal 12″ midrange door speaker for extreme car audio enthusiasts, built to handle up to 2000 watts RMS when paired with a properly tuned PRV DSP and a recommended 150 Hz, 18 dB/octave high pass filter.

Its robust magnet structure is mounted to a reinforced cast-aluminum frame, providing the strength and stability needed for high-output, high-impact performance.

With a Qts of 0.28 and a double roll suspension, the 12MR2000X delivers controlled, powerful response from 400 Hz down to 300 Hz, even at high excursion. Its 6.60 mm Xmax and natural composite cone—made from non-pressed paper for reduced break-up—ensure smooth, clean sound.

Paired with 100 dB sensitivity and high power handling, this midrange driver delivers outstanding dynamics and low distortion, maintaining clarity even at extreme output levels.

General Specifications

  • Nominal Diameter: 12″ (305 mm)
  • Nominal impedance: 8 Ohm
  • Nominal Power Handling*: 1000 Watts
  • Continuous Program Power (RMS)**: 2000 Watts
  • Max Peak Power***: 4000 Watts
  • Sensitivity 2.83V at 1m: 100 dB
  • Recommended Hi Pass Crossover For Full Power Handling: 160 Hz 12db Per Octave Crossover
  • Frequency Response: 100 – 5,300 Hz
  • Voice Coil Diameter: 4″ (100 mm)
  • Voice Coil Wire: Copper
  • Voice Coil Winding Depth: 18.2 mm
  • Former Material: Glass fiber
  • Magnetic Gap Depth: 10.0 mm
  • Frame Material: Die Cast Aluminum
  • Overall Diameter: 12.28″ (312 mm)
  • Front Mount Baffle Cutout: 11.14” (283 mm)
  • Mounting Depth: 4.48″ (114 mm)
  • Overall Depth: 4.96″ (126 mm)
  • Net Weight: 26.65 Lbs (12.08 kg)

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.
**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.
***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

Explore the PRV X Series

6MR600X-NDY 6.5" Neodymium Midrange Speaker 8 Ohm

6MR600X-NDY-4 6.5" Neodymium Midrange Speaker 4 Ohm

8MR600X 8" Ferrite Midrange Speaker 8 Ohm

8MR600X-NDY 8" Neodymium Midrange Speaker 8 Ohm

8MR600X-4 8" Ferrite Midrange Speaker 4 Ohm

10MR1200X 10" Midrange Speaker 8 Ohm

12MR1200X 12" Midrange Speaker 8 Ohm

12MR2000X v2 12" Midrange Speaker 8 Ohm

12MR2000X-NDY 12" Neodymium Midrange Speaker 8 Ohm

Product Details

BrandPRV Audio
Model12MR2000X v2
Part Number294-3405
UPC810075521016
Unit of MeasureEach
Weight28

Product Specifications

Nominal Diameter12"
Power Handling (RMS)1000 Watts
Power Handling (MAX)2000 Watts
Impedance8Ω
Frequency Response100 to 5,300Hz
Sensitivity100dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)64.7Hz
DC Resistance (Re)5.4Ω
Voice Coil Inductance (Le)0.43mH
Mechanical Q (Qms)17.19
Electromagnetic Q (Qes)0.28
Total Q (Qts)0.28
Compliance Equivalent Volume (Vas)1.4ft³
Mechanical Compliance of Suspension (Cms)0.086mm/N
BL Product (BL)23.19T·m
Diaphragm Mass Inc. Airload (Mms)69.86g
Maximum Linear Excursion (Xmax)6.6mm
Surface Area of Cone (Sd)573cm²

Materials of Construction

Voice Coil Wire MaterialCCA
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum

Mounting Information

Overall Outside Diameter12.28"
Depth4.96"
# Mounting Holes8
