GRS 4PF-8 4" Paper Cone Foam Surround Woofer

GRSPart # 292-404
Model: 4PF-8
Thanks to their carefully optimized parameters, GRS 4PF-8 4" poly-laminated paper cone woofers offer a high degree of compatibility when used as replacement speakers.

Key Features

  • Perfect for use in sealed-box home theater and music systems
  • Poly-laminated paper cone, treated foam surround, and polymer dust cap
  • Smooth frequency response with minimal cone breakup
Your Price: $8.49
MSRP: $11.99
Save $3.50 (29%)
Bulk Pricing
Quantity:Qty: 1-3 $8.49/ea
Quantity:Qty: 4+ $7.69/ea
In Stock
Get Notified When Available

We'll send you an email when GRS 4PF-8 4" Paper Cone Foam Surround Woofer is back in stock or available for preorder.

Order in the next 2 hr 42 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

GRS 4PF-8 4" Paper Cone Foam Surround Woofer

Thanks to their carefully optimized parameters, GRS 4PF-8 4" poly-laminated paper cone woofers offer a high degree of compatibility when used as replacement speakers—they also provide excellent performance in new projects, too.


Product Details

BrandGRS
Model4PF-8
Part Number292-404
UPC844632088445
Unit of MeasureEach
Weight1.4

Product Specifications

Nominal Diameter4"
Power Handling (RMS)40 Watts
Power Handling (MAX)80 Watts
Impedance
Frequency Response100 to 10,000Hz
Sensitivity83dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)137Hz
DC Resistance (Re)6.8Ω
Voice Coil Inductance (Le)0.5mH
Mechanical Q (Qms)5.81
Electromagnetic Q (Qes)2.9
Total Q (Qts)1.94
Compliance Equivalent Volume (Vas)0.04ft³
Mechanical Compliance of Suspension (Cms)0.28mm/N
BL Product (BL)3.1T·m
Diaphragm Mass Inc. Airload (Mms)4.8g
Maximum Linear Excursion (Xmax)1.5mm
Surface Area of Cone (Sd)55.2cm²

Materials of Construction

Cone MaterialTreated Paper
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter4.125"
Baffle Cutout Diameter3.75"
Depth2.125"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.1ft³
Sealed F3101.4Hz
