GRS 15PF-8 15" Paper Cone Foam Surround Woofer

Name: GRS 15PF-8 15" Paper Cone Foam Surround Woofer
Brand: GRS
SKU: 292-415
Price: 39.98 USD
Availability: InStock
Rating: 4.7 (76 reviews)

GRSPart # 292-415

Model: 15PF-8

Read 76 Reviews | 185 Questions, 499 Answers or

4 in.5-1/4 in.6-1/2 in.8 in.10 in.12 in.15 in.

The GRS 15PR-8 speaker is the best choice you can make if you need to replace a worn out, blown 15" woofer.

Key Features

Perfect for use in sealed-box home theater and music systems
Poly-laminated paper cone, treated foam surround, and polymer dust cap
Smooth frequency response with minimal cone breakup

Product Details

Brand

GRS

Model

15PF-8

Part Number

292-415

UPC

844632088506

Unit of Measure

Each

Weight

7.55

Product Specifications

Nominal Diameter

15"

Power Handling (RMS)

150 Watts

Power Handling (MAX)

300 Watts

Impedance

8Ω

Frequency Response

25 to 4,000Hz

Sensitivity

88dB 2.83V/1m

Voice Coil Diameter

1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)

30Hz

DC Resistance (Re)

7.3Ω

Voice Coil Inductance (Le)

1.3mH

Mechanical Q (Qms)

5.75

Electromagnetic Q (Qes)

1.91

Total Q (Qts)

1.43

Compliance Equivalent Volume (Vas)

7.91ft³

Mechanical Compliance of Suspension (Cms)

0.23mm/N

BL Product (BL)

9.3T·m

Diaphragm Mass Inc. Airload (Mms)

119.3g

Maximum Linear Excursion (Xmax)

4mm

Surface Area of Cone (Sd)

825.6cm²

Materials of Construction

Cone Material

Treated Paper

Magnet Material

Ferrite

Mounting Information

Overall Outside Diameter

15.125"

Baffle Cutout Diameter

14"

Depth

5.44"

# Mounting Holes

Parts Express Staff Recommended Enclosure Volume

Sealed Volume

3.3ft³

Sealed F3

38.6Hz
