NEW Beyma 6CMV2 6.5" Woofer 8 Ohm

Name: Beyma 6CMV2 6.5" Woofer 8 Ohm
Brand: Beyma
SKU: 253-026
Price: 59.25 USD
Availability: InStock

Beyma

Part #253-026

NEW Beyma 6CMV2 6.5" Woofer 8 Ohm

Beyma

Part #253-026

Model: 6CMV2

6.5 in.8 in.10 in.

The Beyma 6CMV2 is a 6.5" low and mid-frequency transducer designed for professional audio applications requiring high power handling and linear response. Its robust construction and treated components make it suitable for bass and midbass applications in compact vented cabinets.

Key Features

Very linear extended response with low distortion
Treated double roll cloth surround for durability
Pressed steel frame provides structural integrity
Ferrite magnet delivers consistent performance
Designed for bass and midbass applications in compact vented cabinets

Frequently Bought Together

This Product: Beyma 6CMV2 6.5" Woofer 8 Ohm	$59.25
Beyma CP-21/F Compression Tweeter 8 Ohm	$114.00
Parts Express 6" Waffle Style Black Steel Speaker Grille with Rubber Edge	$3.19
Parts Express #8 x 1" Deep Thread Pan Head Screws Black 100 Pcs.	$7.69

Total Price: $184.13

This Product:Beyma 6CMV2 6.5" Woofer 8 Ohm$59.25

Beyma CP-21/F Compression Tweeter 8 Ohm$114.00

Parts Express 6" Waffle Style Black Steel Speaker Grille with Rubber Edge$3.19

Parts Express #8 x 1" Deep Thread Pan Head Screws Black 100 Pcs.$7.69

4 ItemsTotal Price: $184.13

Overview

Beyma 6CMV2 6.5" Woofer 8 Ohm

6CMV2 6.5" Woofer 8 Ohm

The 6CMV2's 220 W AES power handling and 94 dB sensitivity enable it to deliver clear and dynamic sound output, making it suitable for demanding audio applications. Its 1.5" copper wire voice coil enhances thermal stability, contributing to consistent performance over time. The transducer offers a very linear extended response with low distortion, ensuring accurate sound reproduction across its frequency range. The treated double roll cloth surround provides durability and longevity, maintaining performance under rigorous conditions. The pressed steel frame offers structural integrity, while the ferrite magnet ensures consistent performance. Designed for bass and midbass applications in compact vented cabinets, the 6CMV2 provides versatility and high performance for professional audio setups.

Solid Line: On Axis
Dotted Line: 45° Off Axis

Product Details
Brand	Beyma
Model	6CMV2
Part Number	253-026
UPC	8435469050914
Unit of Measure	Each
Weight	5.1

Product Specifications
Nominal Diameter	6-1/2"
Bolt Circle Diameter	6.1
Power Handling (RMS)	220 Watts
Power Handling (MAX)	440 Watts
Impedance	8Ω
Frequency Response	95 to 8,000Hz
Sensitivity	94dB 2.83V/1m
Voice Coil Diameter	1.5"

Thiele-Small Parameters
Resonant Frequency (Fs)	90Hz
DC Resistance (Re)	5.3Ω
Voice Coil Inductance (Le)	0.5mH
Mechanical Q (Qms)	1.4
Electromagnetic Q (Qes)	0.45
Total Q (Qts)	0.34
Compliance Equivalent Volume (Vas)	0.229ft³
Mechanical Compliance of Suspension (Cms)	5.5mm/N
BL Product (BL)	9.4T·m
Diaphragm Mass Inc. Airload (Mms)	0.013g
Maximum Linear Excursion (Xmax)	5.7mm
Surface Area of Cone (Sd)	0.014cm²

Materials of Construction
Surround Material	Cloth
Voice Coil Wire Material	Copper
Basket / Frame Material	Steel
Magnet Material	Ferrite

Mounting Information
Overall Outside Diameter	6.6"
Baffle Cutout Diameter	5.6"
Depth	3.1"
# Mounting Holes	4

Parts Express Staff Recommended Enclosure Volume
Sealed Volume	0.0402ft³
Sealed F3	224.8Hz
Vented Volume	0.102ft³
Vented F3	129.8Hz
