NEW Beyma 10CMV2 10" Woofer 8 Ohm

Beyma
Part #253-028

NEW Beyma 10CMV2 10" Woofer 8 Ohm

Beyma
Part #253-028
Model: 10CMV2

The Beyma 10CMV2 is a 10" low and mid-frequency transducer designed for professional applications requiring high power handling and linear response. Its robust construction and treated components make it suitable for bass and midbass applications in compact vented cabinets.

Key Features
  • 1.5" copper wire voice coil enhances thermal stability​
  • Very linear extended response with low distortion​
  • Treated double roll cloth surround for durability​
  • Optimized pressed steel frame provides structural integrity​
  • Ferrite magnet promises consistent performance​
  • Designed for bass and midbass applications in compact vented cabinets​
Similar items that may interest you:
See all items in Woofers
NEW $75.75
MSRP: $101.00
Save $25.25 (25%)
Bulk Pricing
Order in the next 0 hr 27 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Beyma 10CMV2 10" Woofer 8 Ohm

10CMV2 10" Woofer 8 Ohm

The 10CMV2's 250 W AES power handling and 95 dB sensitivity enable it to deliver clear and dynamic sound output, making it suitable for demanding audio applications. Its 1.5" copper wire voice coil enhances thermal stability, contributing to consistent performance over time. This transducer offers a very linear extended response with low distortion, ensuring accurate sound reproduction across its frequency range. The treated double roll cloth surround provides durability and longevity, maintaining performance under rigorous conditions. The optimized pressed steel frame offers structural integrity, while the ferrite magnet ensures consistent performance. Designed for bass and midbass applications in compact vented cabinets, the 10CMV2 provides versatility and high performance for professional audio setups.​

Solid Line: On Axis
Dotted Line: 45° Off Axis

Product Details

BrandBeyma
Model10CMV2
Part Number253-028
UPC8435469051027
Unit of MeasureEach
Weight7.7

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.5
Power Handling (RMS)250 Watts
Power Handling (MAX)500 Watts
Impedance8Ω
Frequency Response60 to 5,000Hz
Sensitivity95dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)52Hz
DC Resistance (Re)5.9Ω
Voice Coil Inductance (Le)0.8mH
Mechanical Q (Qms)3.8
Electromagnetic Q (Qes)0.47
Total Q (Qts)0.42
Compliance Equivalent Volume (Vas)1.55ft³
Mechanical Compliance of Suspension (Cms)216mm/N
BL Product (BL)13.4T·m
Diaphragm Mass Inc. Airload (Mms)0.042g
Maximum Linear Excursion (Xmax)6.5mm
Surface Area of Cone (Sd)0.038cm²

Materials of Construction

Surround MaterialCloth
Voice Coil Wire MaterialCopper
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.2"
Baffle Cutout Diameter9.1"
Depth4.5"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.455ft³
Sealed F3105.8Hz
Vented Volume1.381ft³
Vented F354.69Hz
