NEW GRS 10" Woofer Surface Mount Poly Cone 4 Ohm 10SMP-4

GRSPart # 292-870
Model: 10SMP-4
The GRS 10SMP-4 is a versatile 10" 4 ohm woofer designed for easy surface mounting and exceptional reliability. It features a damped poly cone and a rubber surround, which work together to produce natural and well-controlled sound output. Additionally, it includes a copper cap that minimizes inductance and distortion. The vented pole piece and aluminum voice-coil former enhance cooling, effectively reducing power compression. With its lightweight 2-layer coil, the 10SMP-4 is ideally suited for sealed enclosures and larger 3-way speaker systems making it an excellent choice for anyone looking to upgrade their older home audio setups.

Key Features

  • Damped poly cone with rubber surround controls resonance for a smooth natural response
  • Copper cap in the motor lowers inductance and distortion for more accurate response
  • Low profile frame supports surface mounting for easy installation
  • Vented pole piece and aluminum voice coil former improve cooling to limit compression
  • Excellent performance in sealed boxes, great choice for larger 3-way designs
Similar items that may interest you:
GRS 10" Woofer Surface Mount Poly Cone 8 Ohm 10SMP-8
Price: $47.98Part # 292-872
Goldwood GW-1034 10" Butyl Surround Woofer 4 Ohm
Price: $55.18Part # 290-361
See all items in Woofers
NEW $47.98
MSRP: $64.99
Save $17.01 (26%)
Bulk Pricing
In Stock
Get Notified When Available

We'll send you an email when GRS 10" Woofer Surface Mount Poly Cone 4 Ohm 10SMP-4 is back in stock or available for preorder.

Order in the next 6 hr 53 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

GRS 10" Woofer Surface Mount Poly Cone 4 Ohm 10SMP-4

The GRS 10SMP-4 is a 10" woofer with a low profile frame designed for easy surface mounting, making it a great choice for new installations or retrofits in older speaker systems. Its design focuses on accurate response and long-term reliability, ensuring that you can enjoy consistent performance for years to come.

Crafted with a damped poly cone and rubber surround, this woofer provides a natural and well-controlled response. The inclusion of a copper cap in the motor helps to reduce inductance and distortion, allowing for clearer and more accurate reproduction. Additionally, an integrated foam gasket ensures an airtight seal within the cabinet. The vented pole piece and aluminum former work together to keep the voice coil cool, minimizing power compression and maintaining sound integrity even at higher volumes. Thanks to a lightweight 2-layer coil the 10SMP-4 delivers good efficiency for high output without requiring a ton of power.

Optimized for use in sealed enclosures, the 10SMP-4 is particularly well-suited for larger 3-way speaker designs. In addition, this driver is compatible with many classic speaker systems making it a practical solution for revitalizing or even enhancing your audio setup.

Product Details

BrandGRS
Model10SMP-4
Part Number292-870
UPC848864079868
Unit of MeasureEach
Weight10

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter10.5
Power Handling (RMS)70 Watts
Power Handling (MAX)140 Watts
Impedance4Ω
Frequency Response24 - 2,000Hz
Sensitivity90dB 2.83V/1m
Voice Coil Diameter1.5"

Thiele-Small Parameters

Resonant Frequency (Fs)28Hz
DC Resistance (Re)3.8Ω
Voice Coil Inductance (Le)0.34mH
Mechanical Q (Qms)2.72
Electromagnetic Q (Qes)0.63
Total Q (Qts)0.51
Compliance Equivalent Volume (Vas)3ft³
Mechanical Compliance of Suspension (Cms)0.51mm/N
BL Product (BL)8.2T·m
Diaphragm Mass Inc. Airload (Mms)63g
Maximum Linear Excursion (Xmax)5mm
Surface Area of Cone (Sd)340cm²

Materials of Construction

Cone MaterialPoly
Surround MaterialRubber
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter11"
Baffle Cutout Diameter9.2"
Depth4.5"
# Mounting Holes5

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.6ft³
Sealed F347Hz
Vented Volume3ft³
Vented F327Hz
