Eminence Kappalite 3015LF Neo 15" Speaker Driver

Eminence SpeakerPart # 290-598
Model: Kappalite 3015LF
The Eminence Kappalite 3015LF 15" speaker is recommended for professional audio and bass in a vented enclosure, thanks to the driver's extended Xmax capabilities and high power handling capacity.

Key Features

  • Neodymium magnet structure delivers incredible performance without the weight
  • Die-cast aluminum basket/heatsink with vented core
  • Copper voice coil with polyimide former
  • Paper cone with solid composition paper dust cap and cloth cone edge
Similar items that may interest you:
Eminence Kappalite 3015 Neo 15" Speaker Driver
Price: $269.99Part # 290-597
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $289.99
+ FREE SHIPPING
MSRP: $339.99
Save $50.00 (15%)
Bulk Pricing
Only 2 In Stock
Get Notified When Available

We'll send you an email when Eminence Kappalite 3015LF Neo 15" Speaker Driver is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Eminence Kappalite 3015LF Neo 15" Speaker Driver

The Eminence Kappalite 3015LF 15" speaker is recommended for professional audio and bass in a vented enclosure, thanks to the driver's extended Xmax capabilities and high power handling capacity. Lightweight yet powerful neodymium magnet.

Product Details

BrandEminence Speaker
ModelKappalite 3015LF
Part Number290-598
UPC876358000623
Unit of MeasureEach
Weight10.7

Product Specifications

Nominal Diameter15"
Power Handling (RMS)450 Watts
Power Handling (MAX)900 Watts
Impedance
Frequency Response40 to 1,500Hz
Sensitivity99.4dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)44Hz
DC Resistance (Re)5.5Ω
Voice Coil Inductance (Le)0.93mH
Mechanical Q (Qms)8.97
Electromagnetic Q (Qes)0.48
Total Q (Qts)0.46
Compliance Equivalent Volume (Vas)5.33ft³
Mechanical Compliance of Suspension (Cms)0.14mm/N
BL Product (BL)17T·m
Diaphragm Mass Inc. Airload (Mms)93g
Maximum Linear Excursion (Xmax)9.6mm
Surface Area of Cone (Sd)881.1cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter15.32"
Baffle Cutout Diameter14.03"
Depth7.25"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.75ft³
Sealed F376.3Hz
Vented Volume7ft³
Vented F340.7Hz
