Dayton Audio RS100-8 4" Reference Full-Range Driver

Dayton AudioPart # 295-352
Model: RS100-8
Dayton Audio Reference Series RS100-8 4" midbass speakers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.

Key Features

  • One of the lowest distortion, highest resolution driver series available
  • Low-distortion high-excursion motor system with two short-circuit paths
  • Compliant suspension and rigid black anodized aluminum cone for strong bass performance
  • Heavy-duty 6-hole cast frame, low-loss rubber surround, and solid aluminum phase plug
  • Designed and engineered in the USA
Your Price: $39.98
MSRP:
Save $12.01 (23%)
Bulk Pricing
324 In Stock
Get Notified When Available

We'll send you an email when Dayton Audio RS100-8 4" Reference Full-Range Driver is back in stock or available for preorder.

Order in the next 3 hr 18 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio RS100-8 4" Reference Full-Range Driver

The Dayton Audio Reference Series was conceived with one goal in mind—low distortion. Each speaker was carefully designed and optimized to offer the highest performance with the lowest distortion levels. At the same time, by focusing on features that contribute to sound quality and eliminating unnecessary frills, the drivers offer value unparalleled in the industry. Dayton Audio Reference Series RS100-8 4" midbass speakers deliver exceptional clarity, detail, and dynamics—and of course, incredibly low distortion.



Product Details

BrandDayton Audio
ModelRS100-8
Part Number295-352
UPC844632088728
Unit of MeasureEach
Weight1.4

Product Specifications

Nominal Diameter4"
Bolt Circle Diameter3.54
Power Handling (RMS)30 Watts
Power Handling (MAX)60 Watts
Impedance8Ω
Frequency Response90 to 20,000Hz
Sensitivity84.6dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)92.2Hz
DC Resistance (Re)6.4Ω
Voice Coil Inductance (Le)0.5mH
Mechanical Q (Qms)2.37
Electromagnetic Q (Qes)0.76
Total Q (Qts)0.58
Compliance Equivalent Volume (Vas)0.05ft³
Mechanical Compliance of Suspension (Cms)0.82mm/N
BL Product (BL)4.2T·m
Diaphragm Mass Inc. Airload (Mms)3.63g
Maximum Linear Excursion (Xmax)3.5mm
Surface Area of Cone (Sd)35.3cm²

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter3.86"
Baffle Cutout Diameter3.04"
Depth2.01"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.05ft³
Sealed F3145Hz
Vented Volume0.15ft³
Vented F365Hz
