  • Beyma 10MI100 MI100 Series 10" Midrange Speaker 8 Ohm

NEW Beyma 10MI100 MI100 Series 10" Midrange Speaker 8 Ohm

BeymaPart # 253-039
Model: 10MI100

The Beyma 10MI100 is a 10″ mid-frequency transducer built for high-quality sound reinforcement systems, especially in live and PA environments. With its high efficiency and linear response, it excels at delivering clean, detailed mids from vocal to upper-range content.

Key Features

  • 3″ edge‑wound aluminum voice coil on polyimide/fiberglass former for thermal stability
  • Extremely linear frequency response with low harmonic distortion
  • 98 dB sensitivity offering strong output from moderate amplification
  • Large magnetic assembly improves heat dissipation under high power
  • Covering 70–4,000 Hz for full mid-range and lower frequency extension
  • Designed explicitly for high-quality mid-frequency reproduction
NEW $219.75
+ FREE SHIPPING
MSRP: $293.00
Save $73.25 (25%)
Bulk Pricing
In Stock
Get Notified When Available

We'll send you an email when Beyma 10MI100 MI100 Series 10" Midrange Speaker 8 Ohm is back in stock or available for preorder.

Order in the next 2 hr 0 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Beyma 10MI100 MI100 Series 10" Midrange Speaker 8 Ohm

Beyma 10MI100 MI100 Series 10" Midrange Speaker 8 Ohm

The 10MI100 combines 350 W AES power handling with 98 dB sensitivity to deliver robust mid-frequency performance without requiring an oversized amplifier. Its 3″ aluminum voice coil, wound on a heat-resistant polyimide/fiberglass former, provides excellent thermal stability during extended use. Beyma highlights its extremely linear frequency response and low harmonic distortion, achieved through precision components and a large ferrite magnetic system designed for efficient heat dissipation. Covering a broad 70–4,000 Hz range, this transducer captures both deep midbass and detailed upper-mids with clarity. Specifically described as designed for high-quality mid-frequency reproduction, the 10MI100 is ideal for professional sound systems, including live PA and mid-top configurations.

Product Details

BrandBeyma
Model10MI100
Part Number253-039
UPC8435469042094
Unit of MeasureEach
Weight16.15

Product Specifications

Nominal Diameter10"
Bolt Circle Diameter9.6
Power Handling (RMS)350 Watts
Power Handling (MAX)700 Watts
Impedance8Ω
Frequency Response70 to 4000Hz
Sensitivity98dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)50Hz
DC Resistance (Re)6.3Ω
Voice Coil Inductance (Le)0.9mH
Mechanical Q (Qms)6.6
Electromagnetic Q (Qes)0.22
Total Q (Qts)0.21
Compliance Equivalent Volume (Vas)1.91ft³
Mechanical Compliance of Suspension (Cms)266mm/N
BL Product (BL)18.7T·m
Diaphragm Mass Inc. Airload (Mms)0.038g
Maximum Linear Excursion (Xmax)4.5mm
Surface Area of Cone (Sd)0.038cm²

Materials of Construction

Voice Coil Wire MaterialAluminum
Voice Coil FormerFiberglass

Mounting Information

Overall Outside Diameter10.3"
Baffle Cutout Diameter9"
Depth4.8"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.117ft³
Sealed F3199.7Hz
Vented Volume0.25ft³
Vented F3127.2Hz
