NEW Visaton FR8WP-8 3.3" Full-Range Driver 8 Ohm White

Visaton
Part #292-7818

NEW Visaton FR8WP-8 3.3" Full-Range Driver 8 Ohm White

Visaton
Part #292-7818
Model: FR 8 WP

The Visaton FR8WP-8 is a 3.3" (8 cm) full-range speaker engineered for durability and high performance in challenging environments. Its saltwater-resistant construction, featuring a molded plastic cone, basket, and grille, ensures longevity in outdoor and marine applications. With a balanced frequency response and IP65-rated protection, it is ideal for outdoor PA systems, solariums, boats, ships, and open vehicles.

Key Features
  • Saltwater-resistant construction for durability in marine and outdoor environments
  • Molded plastic cone, basket, and grille for corrosion resistance
  • Balanced frequency response from 100 Hz to 20,000 Hz for clear audio reproduction
  • Mean sound pressure level of 84 dB (1 W/1 m) for efficient sound output
  • IP65-rated protection against dust and water when installed in a sealed enclosure
  • Operating temperature range from −40 to 80 °C for reliable performance in extreme climates
  • For a quote on a large qty order, please press "Request Large Qty Quote"
NEW $26.35
MSRP: $31.99
Save $5.64 (18%)
Bulk Pricing
Quantity:Qty: 1-9 $26.35/ea
Quantity:Qty: 10+$24.08/ea
Order in the next 1 hr 7 min to ship today. Details

In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Visaton FR8WP-8 3.3" Full-Range Driver 8 Ohm White

The Visaton FR8WP-8 Ohm is a robust 8 cm (3.3") full-range speaker designed for consistent performance in demanding outdoor and marine environments. Its saltwater-resistant construction and IP65-rated protection make it suitable for installations where exposure to moisture, dust, and other environmental factors is unavoidable. Engineered with a balanced frequency response and durable materials, this speaker excels in delivering clear audio for outdoor PA systems, marine applications, and other rugged settings.

Technical Data

  • Rated power: 15 W
  • Maximum power: 25 W
  • Nominal impedance Z: 8 Ohm
  • Frequency response: 100–20000 Hz
  • Mean sound pressure level: 84 dB (1 W/1 m)
  • Opening angle (-6 dB): 114°/4000 Hz
  • Excursion limit: ±3 mm
  • Resonance frequency fs: 158 Hz
  • Magnetic induction: 1.0 T
  • Magnetic flux: 190 µWb
  • Height of front pole-plate: 3 mm
  • Voice coil diameter: 20 mm
  • Height of winding: 4 mm
  • Cutout diameter: 74 mm
  • Net weight: 0.23 kg
  • Connections: 5.2 x 0.5 mm (+)/2.8 x 0.5 mm (-)
  • Protective System: IP 65*)
  • Temperature range: −40 - 80 °C

Product Details

BrandVisaton
ModelFR 8 WP
Part Number292-7818
Unit of MeasureEach
Weight0.51

Product Specifications

Nominal Diameter3-3/10"
Power Handling (RMS)15 Watts
Power Handling (MAX)25 Watts
Impedance
Frequency Response100 to 20000Hz
Sensitivity84dB 2.83V/1m
Voice Coil Diameter0.79"

Thiele-Small Parameters

Resonant Frequency (Fs)158Hz
DC Resistance (Re)4.1Ω
Voice Coil Inductance (Le)0.3mH
Mechanical Q (Qms)2.62
Electromagnetic Q (Qes)1.33
Total Q (Qts)0.88
Compliance Equivalent Volume (Vas)0.01ft³
BL Product (BL)2.8T·m
Diaphragm Mass Inc. Airload (Mms)2.9g
Maximum Linear Excursion (Xmax)3mm
Surface Area of Cone (Sd)30cm²

Mounting Information

# Mounting Holes4
