  • Visaton FR8WP 3.3" Full-Range Driver 8 Ohm Black

Visaton FR8WP 3.3" Full-Range Driver 8 Ohm Black

4 Questions, 4 Answers or
Visaton
Part #292-624

Visaton FR8WP 3.3" Full-Range Driver 8 Ohm Black

Visaton
Part #292-624
Model: FR 8 WP - 8
4 Questions, 4 Answers or

The Visaton FR8WP-8 is a 3.3" (8 cm) full-range speaker engineered for durability and high performance in challenging environments. Its saltwater-resistant construction, featuring a molded plastic cone, basket, and grille, ensures longevity in outdoor and marine applications. With a balanced frequency response and IP65-rated protection, it is ideal for outdoor PA systems, solariums, boats, ships, and open vehicles.

Key Features
  • Saltwater-resistant construction for durability in marine and outdoor environments
  • Molded plastic cone, basket, and grille for corrosion resistance
  • Balanced frequency response from 100 Hz to 20,000 Hz for clear audio reproduction
  • Mean sound pressure level of 84 dB (1 W/1 m) for efficient sound output
  • IP65-rated protection against dust and water when installed in a sealed enclosure
  • Operating temperature range from −40 to 80 °C for reliable performance in extreme climates
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $22.81
MSRP: $26.99
Save $4.18 (15%)
Bulk Pricing
Quantity:Qty: 1-9 $22.81/ea
Quantity:Qty: 10-24 $22.13/ea
Quantity:Qty: 25+$21.19/ea
Order in the next 1 hr 3 min to ship today. Details

Only 4 In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Visaton FR8WP 3.3" Full-Range Driver 8 Ohm Black

The Visaton FR8WP-8 Ohm is a robust 8 cm (3.3") full-range speaker designed for consistent performance in demanding outdoor and marine environments. Its saltwater-resistant construction and IP65-rated protection make it suitable for installations where exposure to moisture, dust, and other environmental factors is unavoidable. Engineered with a balanced frequency response and durable materials, this speaker excels in delivering clear audio for outdoor PA systems, marine applications, and other rugged settings.

Technical Data

  • Rated power: 15 W
  • Maximum power: 25 W
  • Nominal impedance Z: 8 Ohm
  • Frequency response: 100–20000 Hz
  • Mean sound pressure level: 84 dB (1 W/1 m)
  • Opening angle (-6 dB): 114°/4000 Hz
  • Excursion limit: ±3 mm
  • Resonance frequency fs: 158 Hz
  • Magnetic induction: 1.0 T
  • Magnetic flux: 190 µWb
  • Height of front pole-plate: 3 mm
  • Voice coil diameter: 20 mm
  • Height of winding: 4 mm
  • Cutout diameter: 74 mm
  • Net weight: 0.23 kg
  • Connections: 5.2 x 0.5 mm (+)/2.8 x 0.5 mm (-)
  • Protective System: IP 65*)
  • Temperature range: −40 - 80 °C

Product Details

BrandVisaton
ModelFR 8 WP - 8
Part Number292-624
Unit of MeasureEach
Weight0.55

Product Specifications

Nominal Diameter3"
Bolt Circle Diameter3.25
Power Handling (RMS)15 Watts
Power Handling (MAX)25 Watts
Impedance
Frequency Response100 to 20,000Hz
Sensitivity84dB 2.83V/1m
Voice Coil Diameter0.75"

Thiele-Small Parameters

Resonant Frequency (Fs)158Hz
DC Resistance (Re)7.8Ω
Maximum Linear Excursion (Xmax)3mm

Materials of Construction

Cone MaterialPoly
Surround MaterialRubber
Basket / Frame MaterialPolymer
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter3.5"
Baffle Cutout Diameter2.87"
Depth1.5"
# Mounting Holes4
