Neutrik NLT4MXX-BAG speakON STX 4 Pole Male Cable Connector Black-Chrome Metal Housing

NeutrikPart # 092-338
Model: NLT4MXX-BAG
Neutrik's NLT4MXX-Bag is a 4 pole male speakON cable connector, with black-chrome metal housing, and a chuck type strain relief.

Key Features

  • Current rating 40 Amp continuous, 50 Amp audio with 50% duty cycle
  • Robust and durable all metal housing
  • Sealing ring provides weatherproof IP54 rating
  • Reinforced metal quick lock system for ease and precise locking
  • Extra large solder contacts for up to 6mm (AWG10) wires
  • Mate with all available speakON products
Your Price: $15.83
MSRP: $20.99
Save $5.16 (25%)
Bulk Pricing
Quantity:Qty: 1-99 $15.83/ea
Quantity:Qty: 100-249 $14.98/ea
Quantity:Qty: 250+ $14.41/ea
115 In Stock
Get Notified When Available

We'll send you an email when Neutrik NLT4MXX-BAG speakON STX 4 Pole Male Cable Connector Black-Chrome Metal Housing is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Neutrik NLT4MXX-BAG speakON STX 4 Pole Male Cable Connector Black-Chrome Metal Housing

TheSTX Series is the next generation of 4 pole speakON connectors especially designed for amplifier-loudspeaker applications in harsh and demanding environments such as professional touring. The extremely rugged and durable STX Series feature an all metal housing and a built-in gasket providing weatherproof protection to IP54. The 4 pole version is now available as 4 gender system including male cable and female chassis connector.

Product
Connector TypeSpeakon
GenderMale
Electrical
Contact resistance<2 mΩ (after lifetime)
Dielectric strength4 kVdc (peak)
Insulation resistance>10 GΩ (after dampheat)
Rated current per contact40A RMS continuous
Rated current per contact50A audiosignal, duty cycle 50%
Rated voltage250V (Insulation)
AttentionSpeakON is NOT to be used as an AC mains connector!
Mechanical
Cable O.D.9-16 mm
Cable retention force≥220 N (subject to cable O.D. and material)
Lifetime>5,000 mating cycles
Wire size6 mm²
Wire size10 AWG
WiringSolder contacts
Locking deviceQuick lock (latch)
Material
BushingPolyamide (PA 6 15% GR)
Contact plating4 µm Ag
ContactsSpring copper (CuSn0.2)
InsertPolyamide (PA 6 30% GR)
Locking elementZinc diecast (ZnAl4Cu1)
ShellZinc diecast (ZnAl4Cu1)
Strain reliefPolyacetal (POM)
Environmental
ApprovalsUL, cUL
FlammabilityUL 94 HB
Protection classIP 54 (mated condition)
SolderabilityComplies with IEC 68-2-20
Temperature range-30°C to +80°C

Product Details

BrandNeutrik
ModelNLT4MXX-BAG
Part Number092-338
Unit of MeasureEach
Weight0.11

Product Specifications

Circuit4-Pole
GenderMale
Mounting TypeCable Mount
