Mogami W3104 Superflexible High Definition 4 x 12 AWG Speaker Cable 1 ft.

MogamiPart # 103-1026
Model: 3104

The Mogami W3104 is a high-definition, superflexible 4-conductor speaker cable built for professional audio and high-fidelity speaker connections. It features premium materials and construction for audiophile-grade sound transmission and rugged flexibility across custom runs.

Key Features

  • 4-conductor speaker cable with 12 AWG conductors for strong current handling
  • Designed for high-definition audio signal transmission with clear response
  • Superflexible matte black PVC jacket for easy routing and installation
  • Each conductor uses rope-lay Neglex oxygen-free copper for low-loss performance
  • 0.571″ (14.5 mm) diameter suits robust speaker connections
  • Rugged construction for demanding studio, home, or pro audio use
  • Made in Japan
Your Price: $7.69
MSRP: $9.99
Save $2.30 (23%)
Bulk Pricing
Only 73 In Stock
Get Notified When Available

We'll send you an email when Mogami W3104 Superflexible High Definition 4 x 12 AWG Speaker Cable 1 ft. is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Mogami W3104 Superflexible High Definition 4 x 12 AWG Speaker Cable 1 ft.

Mogami W3104 Superflexible High Definition 4 x 12 AWG Speaker Cable

These specialized professional speaker cables were originally developed to achieve maximum performance in advanced Tri Amp systems. They deliver true audiophile-grade signal transmission with clear, transparent sound while maintaining the rugged flexibility required for demanding professional use.

Each conductor is made up of multiple fine strands arranged in a rope-lay using Mogami's well-known NEGLEX oxygen-free copper, housed within color-coded PVC insulation. A durable, low-profile matte black super-flexible PVC jacket surrounds the cable to provide protection and long-lasting reliability.

Specifications and Characteristics

  • Configuration:
  • No. of Conductors: 2
  • Conductor
    -Details: 7/50/0.12 OFC (bare)
    -Size(mm²): 3.96mm² (#12AWG)
  • Insulation Ov. Dia.(mm): 4.5Ø (0.177"Ø) PVC
  • Jacket
    -Ov. Dia.(mm): 14.5Ø (0.571"Ø)
    -Material: Flexible PVC
    -Color: Black
  • DC Resistance (20°C): 0.005Ω/m(0.0015Ω/Ft)
  • Inductance (1kHz, 20°C):
    (Refer to the figures shown in the capacitance data.)
    -1-2: 0.6µH/m(0.18µH/Ft)
    -3-4: 0.6µH/m (0.18µH/Ft)

Common Specs

  • Voltage Breakdown: Must withstand at DC 500V/15sec.
  • Insulation Resistance: 10000 MΩ × m Min. at DC 125V, 20°C
  • Emigration of Jacket Material: Non-Emigrant to ABS resin
  • Applicable Temperature: -20°C‾+70°C (-4°F‾+158°F)
  • Standard: UL13 CL2 75°C

Remarks: Connecting the conductors as diagonal pairs greatly reduces mutual inductance, even though cross-talk interference is negligible.

Product Details

BrandMogami
Model3104
Part Number103-1026
UPC848864028750
Unit of MeasureFeet
Weight1

Product Specifications

Conductors4 Conductor
Jacket ColorBlack
Wire Gauge12
