LaVoce SAF184.50 18" Professional Subwoofer Driver 8 Ohm

LavocePart # 293-752
Model: SAF184.50
LaVoce's SAF184.50 18" professional subwoofer driver is capable of producing extended low frequency output at incredible SPL levels. This high power driver uses a 4.5" voice coil to safely handle up to 1,800 watts RMS. That, combined with 96.5 dB sensitivity, 12.5 mm xmax, and a waterproof treated cone ensures this driver will deliver maximum bass in nearly any situation.

Key Features

  • Massive ferrite motor with extensive venting for high efficiency and low compression
  • 12.5 mm xmax for maximum displacement and incredible impact
  • 4.5" voice coil on fiberglass former to handle up to 1,800 watts RMS (3,600 watts peak)
  • Waterproof treated paper cone makes this driver perfect for use in less than ideal conditions
Similar items that may interest you:
Dayton Audio Pro 18 in. 8 Ohm Neodymium Subwoofer Odeum 18N
Price: $277.98Part # 295-644
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $449.00
+ FREE SHIPPING
MSRP: $670.00
Save $221.00 (33%)
Bulk Pricing
Only 3 In Stock
Get Notified When Available

We'll send you an email when LaVoce SAF184.50 18" Professional Subwoofer Driver 8 Ohm is back in stock or available for preorder.

Order in the next 4 hr 13 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

LaVoce SAF184.50 18" Professional Subwoofer Driver 8 Ohm

Capable of powerful bass output with low distortion the SAF184.50 18" professional subwoofer from LaVoce is ideal for any high SPL speaker system. A massive 4.5" voice coil is wound on a heat resistant fiberglass former to handle up to 3,800 watts peak power. To keep compression to a minimum under high stress situations, the frame and motor include multiple vents for ample air flow across the coil to dissipate any excess heat. Two large diameter spiders and an optimized accordion surround keep the rigid paper cone linear up to the limits of the 25 mm peak to peak excursion and beyond. Holding everything together is a heavy duty cast aluminum frame that is designed to take the beating that is expected in the touring sound environment. All of this extreme construction makes the SAF184.50 18" subwoofer perfect for use in incredibly powerful designs.

Product Details

BrandLavoce
ModelSAF184.50
Part Number293-752
UPC848864061504
Unit of MeasureEach
Weight40.85

Product Specifications

Nominal Diameter18"
Power Handling (RMS)1800 Watts
Power Handling (MAX)3600 Watts
Impedance8Ω
Frequency Response30 to 1,000Hz
Sensitivity96.5dB 2.83V/1m
Voice Coil Diameter4.5"

Thiele-Small Parameters

Resonant Frequency (Fs)35Hz
DC Resistance (Re)5.55Ω
Voice Coil Inductance (Le)2.8mH
Mechanical Q (Qms)5.4
Electromagnetic Q (Qes)0.35
Total Q (Qts)0.33
Compliance Equivalent Volume (Vas)5.72ft³
Mechanical Compliance of Suspension (Cms)0.08mm/N
BL Product (BL)30.72T·m
Diaphragm Mass Inc. Airload (Mms)271g
Maximum Linear Excursion (Xmax)12.5mm
Surface Area of Cone (Sd)1225cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter18.11"
Baffle Cutout Diameter16.64"
Depth9.96"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume3.3ft³
Sealed F357.9Hz
Vented Volume6.5ft³
Vented F334.9Hz
