  • JBL Selenium 12PWX-8R 12" Professional Woofer 8 Ohm

NEW JBL Selenium 12PWX-8R 12" Professional Woofer 8 Ohm

Selenium
Part #264-492

NEW JBL Selenium 12PWX-8R 12" Professional Woofer 8 Ohm

Selenium
Part #264-492
Model: 12PWX-8R

The 12PWX-8R is a professional 10" woofer designed for accurate bass and midbass reproduction. Its reinforced cone and precision-engineered suspension deliver clean response and consistent performance under demanding conditions.

Key Features
  • For bass and mid-bass reproduction for professional sound systems
  • Magnetic assembly optimized by the finite element method (FEA), using a Forged Polar Piece (T-Yoke)
  • Suspension with new geometry, ensuring the product has a flatter, distortion-free curve
  • Cellulose cone using MCF - MULTI COMPOSITE FIBER technology, adding mechanical resistance to the cone
  • Housing made of highly rigid steel sheet, with black epoxy paint
  • Minimum recommended crossover 70Hz
NEW $149.99
+ FREE SHIPPING
Bulk Pricing
Order in the next 1 hr 7 min to ship today. Details

In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

JBL Selenium 12PWX-8R 12" Professional Woofer 8 Ohm

The 12PWX-8R woofer is built for professional audio systems that require tight and controlled bass response without compromising midrange definition. Its magnetic assembly has been developed through Finite Element Analysis (FEA) and incorporates a forged polar piece (T-yoke), resulting in enhanced magnetic control and improved efficiency. The MCF (Multi Composite Fiber) cone construction strengthens the diaphragm, allowing it to maintain tonal integrity under high excursion conditions.

A newly engineered suspension system contributes to a smoother and more linear frequency response, helping eliminate harmonic distortion during playback. Combined with a rigid stamped steel frame coated in black epoxy, the 12PWX-8R offers long-term mechanical stability and resistance to environmental wear. This woofer is suitable for use in both sealed and vented enclosures, making it versatile for various professional applications from portable PA to permanent installations.

With a broad frequency range extending up to 5.0 kHz, the 12PWX-8R covers the entire midbass region with confidence. Whether deployed as a dedicated midbass in multi-way systems or as a compact full-range driver in tighter configurations, it delivers the performance and reliability expected in demanding sound reinforcement settings.

Product Details

BrandSelenium
Model12PWX-8R
Part Number264-492
UPC7896359577354
Unit of MeasureEach
Weight8

Product Specifications

Nominal Diameter12"
Power Handling (RMS)150 Watts
Power Handling (MAX)300 Watts
Impedance8Ω
Frequency Response60 to 5000Hz
Sensitivity95dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)73.1Hz
DC Resistance (Re)5.33Ω
Voice Coil Inductance (Le)0.91mH
Mechanical Q (Qms)123
Electromagnetic Q (Qes)0.96
Total Q (Qts)0.87
Compliance Equivalent Volume (Vas)1.82ft³
Mechanical Compliance of Suspension (Cms)4mm/N
BL Product (BL)9.89T·m
Diaphragm Mass Inc. Airload (Mms)0.08g
Maximum Linear Excursion (Xmax)4mm
Surface Area of Cone (Sd)0.054cm²

Mounting Information

Baffle Cutout Diameter10.98"
Depth4.76"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.638ft³
Sealed F378.58Hz
Vented Volume8.303ft³
Vented F343.77Hz
