Eminence Kappa Pro-10A 10" Cast Frame Driver

Eminence SpeakerPart # 290-426
Model: Kappa Pro-10A
The 500 watt Eminence Kappa Pro-10A 10" Cast Frame Driver is one of the loudest and most durable professional 10" speakers available!

Key Features

  • Kapton coil former
  • Polyamide-imide coated copper voice coil
  • Ferrite magnet
  • Vented and extended pole piece
  • Die-cast aluminum basket
  • Paper cone with cloth accordian surround
  • Solid composition paper dust cap
Similar items that may interest you:
Dayton Audio Pro 10 in. 8 Ohm Neodymium Midbass Woofer Odeum 10N
Price: $110.48Part # 295-640
B&C 10PLB76 10" Woofer
Price: $246.36Part # 294-659
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $164.99
+ FREE SHIPPING
MSRP: $194.99
Save $30.00 (15%)
Bulk Pricing
6 In Stock
Get Notified When Available

We'll send you an email when Eminence Kappa Pro-10A 10" Cast Frame Driver is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Eminence Kappa Pro-10A 10" Cast Frame Driver

The Eminence Kappa Pro-10A 10" cast frame speaker is recommended for professional audio in a sealed midrange, vented midbass, or bass enclosure. It is also suitable for bass guitar loudspeaker systems. Made in the USA. 7-year manufacturer's warranty!

Product Details

BrandEminence Speaker
ModelKappa Pro-10A
Part Number290-426
UPC876358000357
Unit of MeasureEach
Weight15.95

Product Specifications

Nominal Diameter10"
Power Handling (RMS)500 Watts
Power Handling (MAX)1000 Watts
Impedance
Frequency Response102 to 2,000Hz
Sensitivity97dB 2.83V/1m
Voice Coil Diameter3"

Thiele-Small Parameters

Resonant Frequency (Fs)46Hz
DC Resistance (Re)6.5Ω
Voice Coil Inductance (Le)1.15mH
Mechanical Q (Qms)10.1
Electromagnetic Q (Qes)0.2
Total Q (Qts)0.2
Compliance Equivalent Volume (Vas)1.84ft³
Mechanical Compliance of Suspension (Cms)0.31mm/N
BL Product (BL)18.8T·m
Diaphragm Mass Inc. Airload (Mms)38g
Maximum Linear Excursion (Xmax)3.2mm
Surface Area of Cone (Sd)344.9cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter10.25"
Baffle Cutout Diameter9.13"
Depth4.33"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Vented Volume1ft³
Vented F353.4Hz
