  • Crown CT4150 4-Channel Power Amplfier 4 x 125W at 4 Ohms

Crown CT4150 4-Channel Power Amplfier 4 x 125W at 4 Ohms

Crown AudioPart # 245-5145
Model: CT4150
The Crown CT4150 ComTech DriveCore 4-channel power amp delivers professional audio quality in a slim 1RU chassis. Featuring DriveCore technology, the CT4150 efferently produces a strong 150 watts per channel with low distortion. Integrated Life-Safety features including feedback protection ensure reliable performance.

Key Features

  • Flexible input routing to send input signal to any of the four outputs
  • Convection cooling eliminates fan noise
  • Universal power supply allows for use internationally
  • Integrated Life-Safety features including feedback protection
  • DriveCore technology provides excellent efficiency with no compromise in performance
  • Amplifier is stable for 2 to 16 Ohm loads
Your Price: $1,929.00
+ FREE SHIPPING
MSRP: $2,315.00
Save $386.00 (17%)
Bulk Pricing
Out of Stock
Get Notified When Available

We'll send you an email when Crown CT4150 4-Channel Power Amplfier 4 x 125W at 4 Ohms is back in stock or available for preorder.

Special Order Items ships in 20-30 days
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Crown CT4150 4-Channel Power Amplfier 4 x 125W at 4 Ohms

The CT4150 delivers an outstanding 150 watts per channel while remaining housed in a 1RU chassis allowing for use in any standard rack system. Designed with convection cooling, the amp does not require a fan for cooling thus providing silent operation. Flexible input routing allows you to route the input signal to any of the four outputs. Integrated Life-Safety features such as feedback and protection circuitry ensure consistently reliable performance. With a universal power supply, the CT4150 can be used internationally, which is useful for touring applications.

Powering this remarkable amplifier is the pioneering technology of DriveCore, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime. DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages while also maintaining superb sonic characteristics. The end result is an audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design.

Specifications:


• Channels: 4
• Sensitivity: 1.4 V
• Rated power output (all channels driven): 125WPC @ 4 ohms, 125WPC @ 8 ohms
• SNR (below rated power 20-20,000 Hz, A-Weighted): 110 dB
• THD (full rated power, 20-20,000 Hz):<0.05%
• Intermodulation distortion (from 0 dB down to -30 dB):<0.05%
• Frequency response (at 1W, 4/8 ohms): +/-0.5 dB
• Crosstalk (below rated power) 20-1,000 Hz: >70 dB
• Common mode rejection (20-1,000 Hz): >55 dB, typically >70 dB
• Voltage gain:27 dB
• DC offset: +/-20mV
• Idle power consumption (Standard Mode): 17.5W
• IEC power connector: 15A
• Weight: 10 lbs.
• Dimensions: 1.75" H x 19" W x 15.19" D

Product Details

BrandCrown Audio
ModelCT4150
Part Number245-5145
UPC871015004679
Unit of MeasureEach
Weight11.2

Product Specifications

Weight Range10 to 19 lbs.
