  • Crown CT875 8-Channel Power Amplfier 8 x 75W at 4 Ohms

Crown CT875 8-Channel Power Amplfier 8 x 75W at 4 Ohms

Crown AudioPart # 245-5147
Model: CT875
The Crown CT875 ComTech DriveCore 8-channel power amp delivers professional audio quality in a slim 1RU chassis. Featuring DriveCore technology, the CT875 efferently produces a strong 75 watts per channel with low distortion. Integrated Life-Safety features including feedback protection ensure reliable performance.

Key Features

  • Flexible input routing to send input signal to any of the four outputs
  • Convection cooling eliminates fan noise
  • Universal power supply allows for use internationally
  • Integrated Life-Safety features including feedback protection
  • DriveCore technology provides excellent efficiency with no compromise in performance
  • Amplifier is stable for 2 to 16 Ohm loads
Your Price: $2,459.00
+ FREE SHIPPING
Bulk Pricing
Out of Stock
Get Notified When Available

We'll send you an email when Crown CT875 8-Channel Power Amplfier 8 x 75W at 4 Ohms is back in stock or available for preorder.

Special Order Items ships in 20-30 days
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Crown CT875 8-Channel Power Amplfier 8 x 75W at 4 Ohms

The CT875 delivers an outstanding 75 watts per channel while remaining housed in a 1RU chassis allowing for use in any standard rack system. Designed with convection cooling, the amp does not require a fan for cooling thus providing silent operation. Flexible input routing allows you to route the input signal to any of the eight outputs. Integrated Life-Safety features such as feedback and protection circuitry ensure consistently reliable performance. With a universal power supply, the CT875 can be used internationally, which is useful for touring applications.

Powering this remarkable amplifier is the pioneering technology of DriveCore, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime. DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages while also maintaining superb sonic characteristics. The end result is an audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design.

Specifications:


• Channels: 8
• Sensitivity: 1.4 V
• Rated power output (all channels driven): 75 WPC @ 4 ohms, 75 WPC @ 8 ohms
• SNR (below rated power 20-20,000 Hz, A-Weighted): 110 dB
• THD (full rated power, 20-20,000 Hz):<0.05%
• Intermodulation distortion (from 0 dB down to -30 dB):<0.05%
• Frequency response (at 1W, 4/8 ohms): +/-0.5 dB
• Crosstalk (below rated power) 20-1,000 Hz: >70 dB
• Common mode rejection (20-1,000 Hz): >55 dB, typically >70 dB
• Voltage gain:27 dB
• DC offset: +/-20mV
• Idle power consumption (Standard Mode): 23W
• IEC power connector: 15A
• Weight: 10 lbs.
• Dimensions: 1.75" H x 19" W x 15.19" D

Product Details

BrandCrown Audio
ModelCT875
Part Number245-5147
UPC871015004914
Unit of MeasureEach
Weight11.35

Product Specifications

Weight Range10 to 19 lbs.
