  • Dayton Audio DCS165-4 6-1/2" Classic Subwoofer 4 Ohm

Dayton Audio DCS165-4 6-1/2" Classic Subwoofer 4 Ohm

Dayton AudioPart # 295-198
Model: DCS165-4
Capable of impressive low end when installed in enclosures of less than 0.5 cubic feet, the DCS165-4 6-1/2" subwoofer from Dayton Audio's Classic Series is the perfect low cost solution for compact low frequency designs.

Key Features

  • 4-layer VC with polyimide former allows high power handling
  • Vented pole piece and bumped back plate provide plenty of VC travel with minimal compression
  • Copper pole piece cap minimizes inductance
  • Rigid non-pressed treated paper/Kevlar cone with rubber surround
  • Great for home and automotive applications
Similar items that may interest you:
Tang Band W6-1139SIF 6-1/2" Paper Cone Subwoofer Speaker
Price: $92.69Part # 264-919
See all items in Subwoofer Drivers
Your Price: $59.98
MSRP: $77.99
Save $18.01 (23%)
Bulk Pricing
In Stock
Get Notified When Available

We'll send you an email when Dayton Audio DCS165-4 6-1/2" Classic Subwoofer 4 Ohm is back in stock or available for preorder.

Order in the next 5 hr 7 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio DCS165-4 6-1/2" Classic Subwoofer 4 Ohm

Dayton Audio's rugged DCS165-4 6-1/2" subwoofer has all of the performance-enhancing attributes you would expect from a larger high-output subwoofer. With a vented pole piece and 4 ohm, 4-layer voice coil, this driver can handle up 100 watt RMS. The non-pressed paper cone is reinforced with Kevlar to increase stiffness, which promotes linear travel through the limits of its excursion. In addition, the pole piece includes a copper cap that keeps inductance to a minimum. The DCS165-4 driver is ideal for use in small multimedia speakers, portable speakers, or even automotive systems where space is at a minimum.

The Dayton Audio DCS165-4 is used in the following kits:

Dayton Audio 6-1/2" Down Firing Active Mini Subwoofer Kit with 2.1 Channel Amplifier

This compact active subwoofer kit is perfect for powering a compact 2.1 channel speaker system. The Dayton Audio DCS165-4 6-1/2" subwoofer is driven with 60 watts RMS for powerful output and incredible low frequency extension. The Lepai LP210PA amplifier also has 2 x 30 watt RMS outputs to power your left and right speakers. This kit is the perfect start to building your own amazingly convenient self-contained 2.1 channel system.

6-1/2" Down Firing Active Subwoofer Kit

Dayton Audio 6-1/2" Down Firing Passive Mini Subwoofer Kit

With an elegant compact enclosure, this 6-1/2" down-firing subwoofer kit is a great addition to any small stereo or home theater. Using a Dayton Audio DCS165-4 woofer in a vented down-firing configuration, this kit will fit low-key into any décor or under a desk to add high quality bass response and extension to your system.

6-1/2" Down Firing Passive Subwoofer Kit

Blast Box 200 Watt Portable Bluetooth Speaker Kit

Portable, powerful, and fun… The easy to assemble Blast Box portable Bluetooth wireless speaker kit allows you to take high output, Hi-Fi sound with you wherever you go. The 2.1 channel design, capable of 200 watt RMS, uses a pair of 3" aluminum cone woofers and 1" titanium tweeters with a single 6-1/2" high excursion subwoofer. This compact package produces crystal clear midrange and highs with incredibly powerful bass response.

Blast Box Speaker Kit

Product Details

BrandDayton Audio
ModelDCS165-4
Part Number295-198
UPC848791001901
Unit of MeasureEach
Weight4.85

Product Specifications

Nominal Diameter6-1/2"
Power Handling (RMS)100 Watts
Power Handling (MAX)200 Watts
Impedance4Ω
Frequency Response36 to 1,100Hz
Sensitivity87.4dB 2.83V/1m
Voice Coil Diameter1.51"

Thiele-Small Parameters

Resonant Frequency (Fs)35.7Hz
DC Resistance (Re)3.4Ω
Voice Coil Inductance (Le)1.43mH
Mechanical Q (Qms)6.62
Electromagnetic Q (Qes)0.36
Total Q (Qts)0.34
Compliance Equivalent Volume (Vas)0.42ft³
Mechanical Compliance of Suspension (Cms)0.5mm/N
BL Product (BL)9.15T·m
Diaphragm Mass Inc. Airload (Mms)39.5g
Maximum Linear Excursion (Xmax)6mm
Surface Area of Cone (Sd)124.7cm²

Materials of Construction

Cone MaterialPaper / Kevlar
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter6.57"
Baffle Cutout Diameter5.62"
Depth3.25"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.25ft³
Sealed F3101Hz
Vented Volume0.4ft³
Vented F338Hz
