  • Peerless by Tymphany XT25SC90-04 1" Dual Ring Radiator Tweeter

Peerless by Tymphany XT25SC90-04 1" Dual Ring Radiator Tweeter

Peerless by TymphanyPart # 264-1014
Model: XT25SC90-04
The smaller-sized Tymphany XT25SC90-04 features a patented dual concentric diaphragm and a unique waveguide center plug that provide an excellent on- and off-axis response.

Key Features

  • Patented dual ring radiator diaphragm with waveguide center plug
  • Neodymium magnet, low distortion motor
  • Flat response to 40 kHz
Similar items that may interest you:
Peerless by Tymphany XT25BG60-04 1" Dual Ring Radiator Tweeter
Price: $41.98Part # 264-1012
See all items in Tweeters
Your Price: $21.29
MSRP: $32.99
Save $11.70 (35%)
Bulk Pricing
Quantity:Qty: 1-4 $21.29/ea
Quantity:Qty: 5-49 $21.03/ea
Quantity:Qty: 50-249 $20.46/ea
Quantity:Qty: 250+ $19.25/ea
In Stock
Get Notified When Available

We'll send you an email when Peerless by Tymphany XT25SC90-04 1" Dual Ring Radiator Tweeter is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Peerless by Tymphany XT25SC90-04 1" Dual Ring Radiator Tweeter

The smaller-sized Tymphany XT25SC90-04 features a patented dual concentric diaphragm and a unique waveguide center plug that provide an excellent on- and off-axis response. The XT tweeters are acclaimed for their very natural sound with an extremely smooth frequency response extending well beyond the human hearing range.

Product Details

BrandPeerless by Tymphany
ModelXT25SC90-04
Part Number264-1014
UPC844632083686
Unit of MeasureEach
Weight0.15

Product Specifications

Cone / Dome Diameter1"
Cutout Diameter1.85
Tweeter TypeSoft Dome
Power Handling (RMS)100 Watts
Impedance
Frequency Response2,000 to 20,000Hz
Sensitivity90.2dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)830Hz
DC Resistance (Re)3.13Ω
Voice Coil Inductance (Le)0.021mH
Mechanical Q (Qms)7.36
Electromagnetic Q (Qes)1.17
Total Q (Qts)1

Mounting Information

Overall Outside Diameter2.55"
Depth1"
