NEW Onkyo TX-NR5100 NR Series 7.2-Channel 8K AV Receiver

OnkyoPart # 252-551
Model: TX-NR5100

The Onkyo TX-NR5100 is a smart, 7.2‑channel AV receiver that delivers immersive Dolby Atmos and DTS:X home theater performance with advanced 8K video support and seamless connectivity. It pairs powerful surround sound, hassle-free setup tools, and modern streaming features in a versatile centerpiece for both movies and music.

Key Features

  • Supports 8K/60 Hz and 4K/120 Hz via HDMI 2.1 for future-ready video performance
  • Dolby Atmos, DTS:X, and Height Virtualizer deliver immersive 3D sound effects with or without dedicated height speakers
  • AccuEQ room calibration tailors audio to your layout for balanced and accurate sound
  • Smart‑Home ready—works with Sonos, AirPlay 2, Chromecast built-in, Alexa, Hey Google, and more for effortless multi‑room and voice control
  • Advanced video gaming features like VRR, ALLM, and QFT offer ultra-smooth, low-latency gameplay visuals
  • High-res audio support includes DSD up to 256, FLAC, ALAC, and SACD playback for superior music fidelity
  • Klipsch Optimize mode auto-configures crossovers for Klipsch speakers, simplifying setup and enhancing clarity
NEW $519.99
+ FREE SHIPPING
MSRP: $649.99
Save $130.00 (20%)
Bulk Pricing
In Stock
Get Notified When Available

We'll send you an email when Onkyo TX-NR5100 NR Series 7.2-Channel 8K AV Receiver is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Onkyo TX-NR5100 NR Series 7.2-Channel 8K AV Receiver

Onkyo TX-NR5100 NR Series 7.2-Channel 8K AV Receiver

Our SMART AV Receiver™ combines the latest in HDMI 2.1 and 8K tech, high-res audio, and immersive sound via your connected media players, gaming consoles, and advanced audio from your TV apps via eARC for an unparalleled home theater experience.

Klipsch Optimize Mode

Klipsch Optimize Mode makes it simple to perfectly integrate Klipsch Reference and Reference Premiere speakers with your Onkyo AV receiver. By working together, Klipsch and Onkyo programmed precise crossover values tailored for specific Reference Premiere models. All you need to do is select your speaker model for each channel, and the receiver automatically applies the optimized crossover setting for seamless performance.

Shop Klipsch

Smart Home Compatible with Voice Control

The Onkyo TX-NR5100 7.2-Channel 8K SMART AV Receiver integrates effortlessly with modern Smart Home systems, including Apple AirPlay, Alexa, and Google apps. It functions as a highly capable network device, ensuring seamless operation across your multi-room ecosystem* for both convenience and compatibility.

*Requires third-party AI compatible smart home device with microphone

HDMI 2.1 with 8K

HDMI® 2.1 is the latest update to the HDMI® specification, supporting eARC along with higher video resolutions and refresh rates such as 8K60 and 4K120, plus Dynamic HDR formats. With 8K providing twice the horizontal and vertical resolution of 4K and four times the pixel count, combined with a 60Hz refresh rate, you get sharp, smooth playback of fast-moving content. HDMI 2.1 with 8K and eARC ensures your system delivers the cleanest, most precise picture quality both today and well into the future.

Ultimate 4K Gaming Experience

4K/120 delivers ultra-fast motion with UHD images that remain crisp and razor-sharp, making it especially beneficial for sports, action films, and high-performance gaming where smooth clarity is essential.

Additional Features

Built-In Streaming Services
Spotify®, TIDAL, Deezer, TuneIn, and Pandora® are integrated into the system. Use dedicated apps (where available) or the free Onkyo Control App for Apple and Android devices to browse and play music.

Works with Sonos Certified
This receiver can connect to your existing Sonos Home Sound System, or serve as the starting point for a new one, by pairing it with a Sonos Port.* As a Works With Sonos Certified AVR, it provides seamless integration with the Sonos ecosystem, automatically waking, switching inputs, and playing at the set volume using the Sonos Volume-Pass Through feature from the Sonos app.

AccuEQ Calibration Ready
AccuEQ simplifies the initial setup of your home theater system by properly calibrating your receiver and speakers for optimal performance in your listening environment. It measures speaker distance from the listening position, adjusts sound pressure levels, and sets crossovers to route low-frequency content to the subwoofer. The result is balanced, clear, and full-spectrum surround sound.

Dolby Atmos® and DTS:X® – Setting Sound Free
Dolby Atmos® and DTS:X® formats let engineers position sound anywhere in 3D space, moving effects between speakers around the room to immerse your audience in movies and games. These formats also enhance classic titles, with Dolby Surround® and DTS® Neural:X extracting overhead cues in legacy soundtracks for heightened spatial realism.

Dolby Atmos® Height Virtualizer
When playing any Dolby® format, activating Dolby Atmos Height Virtualizer creates a more immersive experience by simulating virtual surround and overhead sound effects from traditional speaker layouts, without the need for extra speakers.

Ready for DTS Play-Fi®
DTS Play-Fi lets you stream high-quality music from online services, networked media servers, or your device library over Wi-Fi® to multiple compatible products using the Onkyo Music Control App for iPad, iPhone, and Android devices. DTS Play-Fi synchronizes music across every room, or allows each family member to play their own selection in a room or group of rooms, creating a versatile multi-room audio system.

Dynamic Audio Amplification
Refined over 70 years, DAA combines a custom High-Current Low-Noise Power Transformer, specially selected capacitors, and discrete amp output stages. Its unique topology prevents phase shift, while high current improves speaker control for true dynamic speed. Designed to drive 4-ohm loads across all channels, DAA delivers both finesse and power.

Comparing the NR Series

TX-NR5100
TX-NR6100
TX-NR7100
Channels
7.27.29.2
Watts Per Channel
80100100
WxDxH
17.13" x 12.91" x 6.30"
17.13" x 6.81" x 14.94"
17.13" x 14.94" x 6.81"
Dolby Atmos Enabled
✔
✔
✔
Works With Sonos
✔
✔
✔
THX Certified
✖
✔
✔
Dirac Live
✖
✖
✔

Specifications

  • Frequency Response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
  • THD (Total Harmonic Distortion): 0.08% (20 Hz–20 kHz, half power)
  • Signal-to-Noise Ratio: 106 dB (Line, IHF-A)
  • Input Sensitivity and Impedance: 200 mV rms/47 kΩ (Line)
  • Rated RCA Output Level and Impedance:
    -1 V rms/470 Ω (Subwoofer pre-out)
    -200 mV rms/470 Ω (Zone 2/Zone B line-out)
  • Speaker impedance: 4-16 Ω
  • Tuner Frequency range:
    -FM : 87.5 MHz–108 MHz
    -AM: 522 kHz–1,611 kHz

  • Audio Inputs: 3*Analog RCA – 1*OPT – 1* COAX – 1*jack 3.5mm
  • HDMI In/Out: 4 / 2
  • Power Supply: AC 220–240 V, 50/60 Hz
  • Power Consumption:
    -Standby 0.15 W
    -No sound 48 W Product
  • Dimensions (W x H x D): 17.13" x 12.91" x 6.30" (435 x 160 x 328 mm)
  • Product Weight: 18.74 lbs. (8.5 kg)
  • Supplied Accessories:
    -Quick Start Guide
    -Remote controller - AAA (R03) batteries x 2
    -Speaker setup microphone

Product Details

BrandOnkyo
ModelTX-NR5100
Part Number252-551
UPC889951003564
Unit of MeasureEach
Weight22.05
