  • Morel ET 338-104 1-1/8" Soft Dome Tweeter Matched Pair

Morel ET 338-104 1-1/8" Soft Dome Tweeter Matched Pair

MorelPart # 277-072
Model: ET 338-104
This pair of Morel ET338-104 Elite tweeters is acoustically matched from the manufacturer and based on the unique qualities of the famous Morel MDT 33.

Key Features

  • Acoustically matched pair
  • IDR™ (Improved Dispersion Recess)
  • Large Hexatech™ aluminum voice coil
  • Triple magnet system
  • Replaceable Accuflex™ diaphragm
  • High power handling
  • Gold plated terminals
Similar items that may interest you:
Morel ET 338 1-1/8" Soft Dome Tweeter Matched Pair
Price: $508.00Part # 277-070
See all items in Tweeters
Your Price: $487.00
+ FREE SHIPPING
MSRP: $658.99
Save $171.99 (26%)
Bulk Pricing
Only 2 In Stock More due any day
Get Notified When Available

We'll send you an email when Morel ET 338-104 1-1/8" Soft Dome Tweeter Matched Pair is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Morel ET 338-104 1-1/8" Soft Dome Tweeter Matched Pair

This pair of Morel ET338 Elite tweeters is acoustically matched from the manufacturer and based on the unique qualities of the famous Morel MDT 33. The new IDR™ (Improved Dispersion Recess) technology enables wider high frequency off-axis dispersion, resulting in a smoother overall performance. An aluminum faceplate with a newly refined texture offers extraordinary acoustical characteristics and exceptional quality finish. Also available with a 110 mm diameter faceplate (277-070). Replacement diaphragm 277-019.

Product Details

BrandMorel
ModelET 338-104
Part Number277-072
UPC844632065958
Unit of MeasurePairs
Weight3

Product Specifications

Cone / Dome Diameter1.125"
Cutout Diameter2.99
Tweeter TypeSoft Dome
Power Handling (RMS)200 Watts
Impedance
Frequency Response1,800 to 20,000Hz
Sensitivity92.5dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)700Hz
DC Resistance (Re)5.2Ω

Mounting Information

Overall Outside Diameter4.09"
Depth2.48"
