BUYOUT EAS 12D138B 3" x 5" Paper Cone Full-Range Speaker 16 Ohms

Factory Buyouts
Part #299-4262

BUYOUT EAS 12D138B 3" x 5" Paper Cone Full-Range Speaker 16 Ohms

Factory Buyouts
Part #299-4262
Model: EAS12D138B

The EAS 12D138B 3" x 5" paper cone full-range driver uses a paper cone and treated paper surround for smooth and natural response along with reliable performance. The common size and 4-hole mounting flange make this a popular replacement driver for many TV's.

Key Features
  • Naturally damped paper cone for smooth, controlled response on and off axis
  • Common size and shape for easy replacement of damaged and worn out drivers
  • Shielded magnet for use near sensitive electronic equipment
  • Perfect for use in slim designs such as sound bars and portable speakers
BUYOUT $2.88
Bulk Pricing
Quantity:Qty: 1-29 $2.88/ea
Quantity:Qty: 30-59 $2.56/ea
Quantity:Qty: 60+$2.45/ea
Order in the next 0 hr 52 min to ship today. Details

135In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

EAS 12D138B 3" x 5" Paper Cone Full-Range Speaker 16 Ohms

The 12D138B 3" x 5" paper cone full-range driver uses a paper cone and treated paper surround for clean, natural audio reproduction. The low-profile mounting flange and 16 ohm impedance make this a great contender for use in line arrays. In attrition, with a shielded magnet assembly, this driver is a great choice for use near electronic devices that are sensitive to stray magnetic fields.

Product Details

BrandFactory Buyouts
ModelEAS12D138B
Part Number299-4262
UPC848864073767
Unit of MeasureEach
Weight0.5

Product Specifications

Bolt Circle Diameter4.375
Power Handling (RMS)10 Watts
Power Handling (MAX)20 Watts
Impedance16Ω
Frequency Response90 to 12,000Hz
Sensitivity75dB 2.83V/1m
Voice Coil Diameter0.6"

Thiele-Small Parameters

Resonant Frequency (Fs)109Hz
DC Resistance (Re)15.6Ω
Voice Coil Inductance (Le)0.33mH
Mechanical Q (Qms)5.05
Electromagnetic Q (Qes)3.06
Total Q (Qts)1.91
Compliance Equivalent Volume (Vas)0.031ft³
BL Product (BL)2.71T·m
Diaphragm Mass Inc. Airload (Mms)2.1g
Maximum Linear Excursion (Xmax)1mm
Surface Area of Cone (Sd)24.6cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialPaper
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter3" x 5.125"
Baffle Cutout Diameter4.875" x 2.875"
Depth2.125"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.03ft³
Sealed F3103Hz
