Dayton Audio DCS385-4 15" Classic Subwoofer 4 Ohm

Dayton Audio
Part #295-206

Dayton Audio DCS385-4 15" Classic Subwoofer 4 Ohm

Dayton Audio
Part #295-206
The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses.
Key Features
  • Sturdy stamped steel frame
  • Vented pole piece and bumped back plate
  • Inductance-reducing copper pole piece cap
  • Treated non-pressed paper/Kevlar cone with rubber surround
  • 4-layer VC with polyimide former
  • Great for home and automotive applications
  • Five year warranty
Your Price: $109.98
+ FREE SHIPPING
MSRP: $168.99
Save $59.01 (35%)
Bulk Pricing
Quantity:Qty: 1-3 $109.98/ea
Quantity:Qty: 4+$104.15/ea
Ships next business day. Details

In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Dayton Audio DCS385-4 15" Classic Subwoofer 4 Ohm

The Dayton Audio Classic Series subwoofers offer solid value at lower price points. No compromises were made in the design, materials, or construction of these rugged 4-ohm powerhouses. The drivers feature a vented pole piece with copper cap, bumped back plate for improved excursion capability, Kevlar reinforced cone with rubber half-roll surround, and a high-temperature 4-layer copper voice coil wound on a polyimide former.



Product Details

BrandDayton Audio
ModelDCS385-4
Part Number295-206
UPC844632080685
Unit of MeasureEach
Weight16.85

Product Specifications

Nominal Diameter15"
Power Handling (RMS)300 Watts
Power Handling (MAX)600 Watts
Impedance4Ω
Frequency Response19 to 200Hz
Sensitivity91.7dB 2.83V/1m
Voice Coil Diameter2.57"

Thiele-Small Parameters

Resonant Frequency (Fs)17.5Hz
DC Resistance (Re)3.3Ω
Voice Coil Inductance (Le)2.2mH
Mechanical Q (Qms)5.27
Electromagnetic Q (Qes)0.42
Total Q (Qts)0.39
Compliance Equivalent Volume (Vas)10.98ft³
Mechanical Compliance of Suspension (Cms)0.3mm/N
BL Product (BL)15.4T·m
Diaphragm Mass Inc. Airload (Mms)273g
Maximum Linear Excursion (Xmax)9.3mm
Surface Area of Cone (Sd)850.1cm²

Materials of Construction

Cone MaterialPaper / Kevlar
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter15.24"
Baffle Cutout Diameter13.78"
Depth7.3"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume2.1ft³
Sealed F342Hz
Vented Volume6ft³
Vented F323Hz
