B&C's ME15 1" exponential cast aluminum horn features very good loading down to 1.5 kHz. The ME15's durable aluminum construction and carefully developed flare geometry guarantee the smooth, consistent high fidelity output that is demanded by professional audio and critical studio monitoring applications.
Specifications: • Nominal dispersion: 90°H x 60°V • Minimum frequency: 1,500 Hz • Throat diameter: 1" • Dimensions: 5.4"H x 5.9"W x 3.5"D • Cutout dimensions: 4.3"H x 4.7"W • Mounting type: Standard 2 bolt.
B&C Speakers produces a series of horns for compression drivers ranging from constant directivity models, known for their great consistency in angular coverage, to exponential models, which optimize acoustical loading and sound energy transfer. Standardized driver mounting flanges give the designer the freedom to choose the best horn/driver combination for each project.
All horns are made of cast aluminum, resulting in a robust structure that is free from resonances. The only exception to this method is the ME10; a new design that is made from precision molded plastic and incorporates stiffeners that add to its structural integrity. B&C combines advanced design techniques with critical listening tests to manufacture horns that exhibit precise pattern control, excellent driver loading, and low distortion and coloration.
Product Details | |
|---|---|
| Brand | B&C Speakers |
| Model | ME15 |
| Part Number | 294-620 |
| UPC | 844632001871 |
| Unit of Measure | Each |
| Weight | 0.9 |
Product Specifications | |
|---|---|
| Construction | Aluminum |
| Entry / Throat Diameter | 1" |
| Mounting Type | 2-Bolt |
