B&C 8NDL64 8" Neodymium Woofer

B&C SpeakersPart # 294-6012
Model: 8NDL64
B&C's 8NDL64 8" neodymium-powered 8 ohm woofer offers a lightweight (only 6.16 lbs.), neodymium driver with 700 watts continuous power handling!

Key Features

  • 4.5 mm Xmax ensures low distortion at high output
  • 700 watts continuous power handling for reliable long term use
  • 2.5" copper voice coil allows high power handling
  • Vented voice coil gap for reduced power compression
Similar items that may interest you:
Beyma 8MC500Nd MC Series 8" Neo Woofer 8 Ohm
Price: $243.75Part # 253-011
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Your Price: $176.58
+ FREE SHIPPING
MSRP: $294.30
Save $117.72 (40%)
Bulk Pricing
Back-Ordered
Get Notified When Available

We'll send you an email when B&C 8NDL64 8" Neodymium Woofer is back in stock or available for preorder.

Estimated back in stock 7/16/2025
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

B&C 8NDL64 8" Neodymium Woofer

The B&C 8NDL64 8" speaker encompasses a vented voice coil gap that dissipates heat for reduced power compression, and a shorting copper cap for extended HF response. The use of a 2.5" copper voice coil and double roll surround allows for 700 watts continuous power handling.

Product Details

BrandB&C Speakers
Model8NDL64
Part Number294-6012
UPC848864016641
Unit of MeasureEach
Weight7.05

Product Specifications

Nominal Diameter8"
Bolt Circle Diameter8.3
Power Handling (RMS)700 Watts
Impedance
Frequency Response80-4000Hz
Sensitivity97dB 2.83V/1m
Voice Coil Diameter2.5"

Thiele-Small Parameters

Resonant Frequency (Fs)80Hz
DC Resistance (Re)
Voice Coil Inductance (Le)0.62mH
Mechanical Q (Qms)11
Electromagnetic Q (Qes)0.24
Total Q (Qts)0.25
Compliance Equivalent Volume (Vas)0.35ft³
BL Product (BL)17.5T·m
Diaphragm Mass Inc. Airload (Mms)28g
Maximum Linear Excursion (Xmax)4.5mm
Surface Area of Cone (Sd)220cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialCast Aluminum
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter8.80"
Baffle Cutout Diameter7.40"
Depth3.74"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.22ft³
Sealed F3293Hz
Vented Volume0.45ft³
Vented F381.3Hz
