Yorkville CA1 Coliseum Series 120W Installation Mixer / Power Amplifier 70V / 4 Ohm

Name: Yorkville CA1 Coliseum Series 120W Installation Mixer / Power Amplifier 70V / 4 Ohm
Brand: Yorkville
SKU: 245-959
Price: 419 USD
Availability: InStock

YorkvillePart # 245-959

Model: CA1

2 Questions, 4 Answers or

Versatile input mixing capabilities make the Yorkville CA1 70V installation amplifier the perfect amp for small churches, boardrooms and conference room PA applications. Unlike most installation amplifiers in this class, the CA1 delivers flexible input and output options for use with many installation jobs.

Key Features

180 watt 6 channel 70V installation amplifier with 4 ohm compatibility
Versatile input mixing capabilities with XLR / TRS balanced combo-jack / attenuated RCA unbalanced inputs
Individual volume control, clip & activity LED's per channel
User selectable phantom power (available on three channels)

See all items in Commercial 70V Mixer-Amplifiers

Your Price: $419.00

+ FREE SHIPPING

MSRP: $559.00

Bulk Pricing

In Stock

Get Notified When Available

We'll send you an email when Yorkville CA1 Coliseum Series 120W Installation Mixer / Power Amplifier 70V / 4 Ohm is back in stock or available for preorder.

Ships next business day. Details

QtyQuantity:

Free Shipping available on orders over $99.00 in the US. Details

60 Day No Hassle Return Policy

Overview

Yorkville CA1 Coliseum Series 120W Installation Mixer / Power Amplifier 70V / 4 Ohm

The Coliseum CA1 public address amplifier has been designed specifically for installations where a versatile paging system with high quality music playback is required.

Ideal for restaurants, small clubs, offices and retail environments where a simple and reliable system capable of servicing multiple paging zones is required. Multiple inputs for microphone or source material, and voice activated paging from either a microphone or telephone matrix means the CA1 can be used in virtually any application. Selectable phantom power is available on three channels to drive condenser microphones, the type most commonly used on podiums or as a lavaliere (tie clip) microphone

XLR / TRS balanced combo-jack inputs and attenuated RCA unbalanced inputs ensure the CA1 system can interface with any source (CD, Cassette, Satellite Tuner, DVD or video system) your installation may require.

Capable of driving either a 4 ohm speaker load, or four separate 70 volt speaker systems (one ‘system’ per zone), the CA1 system delivers 180 watts (mono). A pre-amp output is available to feed an auxiliary power amplifier or active subwoofer to enhance the system, or to feed video or audio recording equipment

Specifications: • Number of channels: 6 • Inputs: 3 x XLR / TRS Combo-jacks, 2 x unbalanced RCA • Phantom power: 48V • SNR: > 55 dB • Frequency response: 50 - 15,000 Hz • Power @ 4 ohms: 180 watts • Power (70V): 180 watts • THD: < 1% @ 1kHz(dB) • Cooling: Passive • Construction: Steel • Rackmount: Yes • Headphone out: Yes • Record out: Yes - main output • Other features: Zone paging, telephone interface • Dimensions: 12" x 19" x 6".

Constant Voltage (70-Volt) Audio Systems

Audio distribution systems, especially those commonly used in department stores, warehouses, restaurants, etc., require that many loudspeakers be driven from a single audio amplifier over long runs of speaker wire. The "constant voltage" or "high impedance distribution" audio systems can be complex to understand at first, however, provides many advantages. Learn how to design your own 70-volt or 25-volt loudspeaker system.

Learn More

Product Details
Brand	Yorkville
Model	CA1
Part Number	245-959
UPC	840402011187
Unit of Measure	Each
Weight	28.75
