Visaton W250-8 10" Woofer 8 Ohm

Visaton
Part #292-586

Visaton W250-8 10" Woofer 8 Ohm

Visaton
Part #292-586
Model: W250 - 8
The 9067 W250 10" woofer from Visaton is a great replacement woofer for many sealed and ported cabinet speakers.
Key Features
  • Foam surround and ribbed paper cone for a classic sound
  • 3 mm of Xmax and excursion limit of ±10 mm for good bass performance
  • Great replacement driver for sealed and ported speaker cabinets
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $64.01
MSRP: $75.99
Save $11.98 (16%)
Bulk Pricing
Quantity:Qty: 1-9 $64.01/ea
Quantity:Qty: 10-24 $62.25/ea
Quantity:Qty: 25+$59.80/ea
Ships next business day. Details

Only 1 In Stock

More due any day
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton W250-8 10" Woofer 8 Ohm

Visaton's 9067 W250 10" woofer is designed to be a high performance replacement speaker at a budget price point. A foam surround and ribbed, treated paper cone offer longevity while capturing that classic sound from the golden era of loudspeakers. A healthy 3 mm of Xmax and excursion limit of ±10 mm allows this driver to pump out some serious bass in many different sized sealed, acoustic suspension or ported speaker cabinets. A smooth frequency response makes for easy integration with many different midrange speakers and tweeters.

Note: For best bass response, install the W250 into one of the following cabinets:
• A 1.06 cubic foot cabinet tuned to 46 Hz with a 2-1/2" diameter port that is 4-3/8" long.
• A 1.77 cubic foot cabinet tuned to 38 Hz with a 2-1/2" diameter port that is 3-1/2" long.
• A 2.47 cubic foot cabinet tuned to 38 Hz with a 2-1/2" diameter port that is 3-1/8" long.

Product Details

BrandVisaton
ModelW250 - 8
Part Number292-586
Unit of MeasureEach
Weight3.7

Product Specifications

Nominal Diameter10"
Power Handling (RMS)90 Watts
Power Handling (MAX)130 Watts
Impedance8Ω
Frequency Response37 to 6,000Hz
Sensitivity90dB 2.83V/1m
Voice Coil Diameter1.38"

Thiele-Small Parameters

Resonant Frequency (Fs)37Hz
DC Resistance (Re)6.8Ω
Voice Coil Inductance (Le)1.1mH
Mechanical Q (Qms)3.57
Electromagnetic Q (Qes)1
Total Q (Qts)0.78
Compliance Equivalent Volume (Vas)4.77ft³
Maximum Linear Excursion (Xmax)3mm

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialFoam

Mounting Information

Overall Outside Diameter10.03"
Baffle Cutout Diameter9.29"
Depth4.02"

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.25ft³
Sealed F358Hz
