CLEARANCE Visaton FRWS5SC-8 2" Full-Range Driver 8 Ohm

Visaton
Part #292-632

CLEARANCE Visaton FRWS5SC-8 2" Full-Range Driver 8 Ohm

Visaton
Part #292-632
Model: FRWS5SC-8
Ideally suited for general music and voice reproduction, Visaton's FRWS 5 SC 8 Ohm 2" full-range driver with its shielded Alnico magnet is perfect for multimedia applications.
Key Features
  • Alnico motor keeps size and weight to a minimum
  • Moisture resistant paper cone for natural response
  • Front foam gasket for a good seal when rear mounting
  • High Qts make this driver suitable in free air applications
  • For a quote on a large qty order, please press "Request Large Qty Quote"
CLEARANCE $9.00
MSRP: $18.99
Save $9.99 (53%)
Bulk Pricing
Ships next business day. Details

97In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton FRWS5SC-8 2" Full-Range Driver 8 Ohm

The FRWS 5 SC, magnetically shielded 2" full-range driver, features a highly compact construction due to lightweight alnico magnet. Features a balanced frequency response from 350 Hz and good omnidirectional sound distribution. This is an excellent driver for music and voice reproduction in multimedia applications such as TVs, PCs, and sound bars.

Product Details

BrandVisaton
ModelFRWS5SC-8
Part Number292-632
Unit of MeasureEach
Weight0.13

Product Specifications

Nominal Diameter2"
Bolt Circle Diameter2.5
Power Handling (RMS)4 Watts
Power Handling (MAX)8 Watts
Impedance8Ω
Frequency Response200 to 20,000Hz
Sensitivity80dB 2.83V/1m
Voice Coil Diameter0.5"

Thiele-Small Parameters

Resonant Frequency (Fs)350Hz
DC Resistance (Re)7.2Ω
Voice Coil Inductance (Le)0.1mH
Mechanical Q (Qms)4.1
Electromagnetic Q (Qes)9.35
Total Q (Qts)2.85
Compliance Equivalent Volume (Vas)0.0074ft³
BL Product (BL)1T·m
Maximum Linear Excursion (Xmax)2mm
Surface Area of Cone (Sd)12cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialRubber
Voice Coil Wire MaterialCopper
Voice Coil FormerPaper
Basket / Frame MaterialSteel
Magnet MaterialAlNiCo

Mounting Information

Overall Outside DiameterSquare: 2"
Baffle Cutout Diameter1.75"
Depth0.905"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.015ft³
Sealed F3285.2Hz
