Visaton FRWS 5 R 2" Full-Range Speaker 8 Ohm

VisatonPart # 292-650
Model: FRWS 5 R
Designed to reproduce a majority of the audio spectrum, Visaton's 8 ohm 2" FRWS 5 R full-range driver features a minimalist pressfit frame, wide dispersion, and detailed high frequency response.

Key Features

  • Lightweight paper cone delivers smooth high frequency response
  • Water resistant paper cone with cloth surround for smooth frequency response
  • Pressfit stamped steel frame with front mounted cardboard gasket
  • Common size used in many portable Bluetooth speakers
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $12.76
MSRP: $15.99
Save $3.23 (20%)
Bulk Pricing
Quantity:Qty: 1-9 $12.76/ea
Quantity:Qty: 10-24 $12.38/ea
Quantity:Qty: 25+ $11.85/ea
36 In Stock
Get Notified When Available

We'll send you an email when Visaton FRWS 5 R 2" Full-Range Speaker 8 Ohm is back in stock or available for preorder.

Order in the next 3 hr 19 min to ship today. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Visaton FRWS 5 R 2" Full-Range Speaker 8 Ohm

The 2" FRWS 5 R full-range HiFi driver from Viaston features a compact round pressfit frame and is suitable as a midrange driver in three-way speakers, wide-band use in industrial PA speaker systems, or a full-rage in extremely compact portable speakers. The slim design is also great for use in electronic musical instruments and toys. A pressfit steel frame, cloth surround, and water resistant paper cone are used to maximize both durability and value, making the 8 ohm FRWS 5 R a great bang-for-the-buck speaker.

Product Details

BrandVisaton
ModelFRWS 5 R
Part Number292-650
Unit of MeasureEach
Weight0.22

Product Specifications

Nominal Diameter2"
Power Handling (RMS)4 Watts
Power Handling (MAX)10 Watts
Impedance8Ω
Frequency Response150 to 20,000Hz
Sensitivity84dB 2.83V/1m
Voice Coil Diameter0.55"

Thiele-Small Parameters

Resonant Frequency (Fs)250Hz
DC Resistance (Re)6.8Ω
Voice Coil Inductance (Le)0.1mH
Mechanical Q (Qms)3.31
Electromagnetic Q (Qes)3.22
Total Q (Qts)1.63
Compliance Equivalent Volume (Vas)0.0035ft³
Mechanical Compliance of Suspension (Cms)0.811mm/N
BL Product (BL)1.28T·m
Maximum Linear Excursion (Xmax)0.35mm

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter1.96"
Baffle Cutout Diameter1.77"
Depth0.98"

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.008ft³
Sealed F3209.6Hz
