  • Visaton DSM25FFL 1" Titanium Dome Tweeter 8 Ohm

Visaton DSM25FFL 1" Titanium Dome Tweeter 8 Ohm

Visaton
Part #292-688

Visaton DSM25FFL 1" Titanium Dome Tweeter 8 Ohm

Visaton
Part #292-688
Model: DSM25FFL

The Visaton DSM25FFL 1" High-End titanium dome driver, is expertly crafted for high frequencies above 2000 Hz. Its ultra-light titanium dome and highly damped surround guarantee linear frequency response and no partial oscillations.

Key Features
  • Exceptionally balanced dome driver
  • Designed for high-range frequencies above 2000 Hz
  • Ultra-light titanium dome and highly damped surround
  • Easily integrated into various high-end speaker systems
  • High-end performance at an excellent value
  • For a quote on a large qty order, please press "Request Large Qty Quote"
Your Price: $82.48
MSRP: $94.11
Save $11.63 (12%)
Bulk Pricing
Quantity:Qty: 1-9 $82.48/ea
Quantity:Qty: 10+$75.88/ea
Order in the next 0 hr 57 min to ship today. Details

In Stock

Free Shipping available on orders over $99.00 in the US. Details

Overview

Visaton DSM25FFL 1" Titanium Dome Tweeter 8 Ohm

Choose the Visaton DSM25FFL 1" dome driver for superior high-range audio performance in your speaker systems. This model is ideal for use in advanced two and three-way speaker designs, and even in high-end multi-way systems. The ultra-light titanium dome in conjunction with a highly damped surround ensures linear frequency response with no partial oscillations, offering a sound experience that is both powerful and precise. The DSM25FFL boasts an extraordinarily high magnetic flux in the ferrofluid-filled airgap, providing high efficiency and exceptional power handling. This makes it a perfect choice for those who seek to enjoy the finest audio reproduction.

Product Details

BrandVisaton
ModelDSM25FFL
Part Number292-688
Unit of MeasureEach
Weight1.25

Product Specifications

Cutout Diameter3.14
Tweeter TypeMetal Dome
Power Handling (RMS)120 Watts
Impedance
Frequency Response1,000 to 30,000Hz
Sensitivity90dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)1600Hz

Mounting Information

Overall Outside Diameter3.77"
Depth1.04"
