CLEARANCE Ultra-Bright Red 5mm LED 5000 mcd

Parts ExpressPart # 070-501
Select only ultra-bright LEDs for your next project. A high intensity design offers you the ability to dial in just the right amount of light for your application.

Key Features

  • Ultra bright 5 mm LED
  • Lights red but is water clear when turned off
Get Notified When Available

We'll send you an email when Ultra-Bright Red 5mm LED 5000 mcd is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Ultra-Bright Red 5mm LED 5000 mcd

Select only ultra-bright LEDs for your next project. A high intensity design offers you the ability to dial in just the right amount of light for your application. Choose from a wide variety of colors. Each ultra-bright LED features a clear lens, and a 5 mm diameter (T1-3/4).

Description:

  • Source material: AlGalnP
  • Emitting color: RED

Electrical/Optical Characteristics (TA= 25°C, IF= 20 mA):

  • Luminous intensity (Lv): 5000 mcd
  • Forward voltage (VF): 2.0 VDC (typ), 2.5 (max)
  • Viewing angle (2?1/2): 15°

Absolute Maximum Rating (TA= 25°C):

  • Peak forward current: 100 mA
  • Average forward current (IF): 50 mA
  • Reverse voltage (VR): 5.0 V
  • Reverse current (IR, VR=5V): 10 µA
  • Operating temperature: -25°C to +85°C

Note: LEDs are static-sensitive devices. Observe static sensitivity handling precautions. When forming leads, the leads should be bent at a point at least 3 mm from the base. Avoid damage to LEDs by soldering for no longer than 3 seconds with 700° iron. Always use current limiting series resistors with LEDs. For help with designing your project and selecting correct resistors, use the LED Wizard by Rob Arnold.



Product Details

BrandParts Express
Part Number070-501
UPC844632079214
Unit of MeasureEach
Weight0.001

Product Specifications

Application TypeSteady
Emitting ColorRed
Lens Type / ColorWater Clear
Luminous Intensity5000 mcd
Size5mm / T-1 3/4
