Timpano Audio TPT-MB12-2K5 12" Midbass Speaker 8 Ohm

Timpano AudioPart # 294-4104
Model: TPT-MB12-2K5
1 Question, 2 Answers or
One of Timpano Audio’s most powerful midbass drivers, the massive TPT-MB12 2K5 12” professional midbass driver is built to produce extreme output capability with low distortion and outstanding durability. With a 4” voice coil, optimized suspension, 98 dB sensitivity, and reinforced cast aluminum frame, this driver is ideal for use in any high SPL design.

Key Features

  • 98 dB sensitivity and 1,250 watts RMS power handling to produce maximum output
  • 7 mm of excursion allows excellent displacement capability for high impact midbass punch
  • Huge 4” diameter voice coil improves power handling and reliability
  • High grade soft parts improve durability under the stress of high excursion
Your Price: $159.95
+ FREE SHIPPING
MSRP: $199.94
Save $39.99 (20%)
Bulk Pricing
5 In Stock
Get Notified When Available

We'll send you an email when Timpano Audio TPT-MB12-2K5 12" Midbass Speaker 8 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Timpano Audio TPT-MB12-2K5 12" Midbass Speaker 8 Ohm

Timpano Audio’s TPT-MB12 2K5 12” professional midbass is capable of delivering enough output to add some serious kick to the most powerful sound systems. With a 4” diameter CCA voice coil and extensive venting, this driver can handle up to 1,250 watts RMS (2,500 watts max) for long periods while keeping power compression to a minimum. The specially designed and optimized spider and surround allows reliable performance and durability even when repeatedly pushed to the limit. 7 mm of excursion (14 mm peak to peak) gives this driver ample displacement to provide a midbass punch that you will feel.

Product Details

BrandTimpano Audio
ModelTPT-MB12-2K5
Part Number294-4104
UPC611056239513
Unit of MeasureEach
Weight25.95

Product Specifications

Nominal Diameter12"
Power Handling (RMS)1250 Watts
Power Handling (MAX)2500 Watts
Impedance
Frequency Response60 to 5,500Hz
Sensitivity98dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Maximum Linear Excursion (Xmax)7mm

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter12.6"
Baffle Cutout Diameter11.25"
Depth5.47"
# Mounting Holes8
