Tectonic Metal Cup Audio Exciter 19mm 3W 8 Ohm TEAX19C01-8

TectonicPart # 297-208
Model: TEAX19C01-8
The Tectonic TEAX19C01-8 exciter employs proprietary technologies and premium materials to produce a transducer that converts almost any surface into an audio loudspeaker.

Key Features

  • Small size for use where speakers wouldn't be possible
  • Turn any surface into a HiFi speaker
Similar items that may interest you:
Dayton Audio Coin Type Audio Exciter 19mm 5W 4 Ohm DAEX19CT-4
Price: $7.49Part # 295-218
See all items in Exciters & Tactile Transducers
Your Price: $5.48
+ FREE SHIPPING
MSRP: $18.99
Save $13.51 (71%)
Bulk Pricing
Quantity:Qty: 2016+ $5.48/ea
Out of Stock
Get Notified When Available

We'll send you an email when Tectonic Metal Cup Audio Exciter 19mm 3W 8 Ohm TEAX19C01-8 is back in stock or available for preorder.

Ships in 90-120 days, minimum order quantity 2016 pcs.
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Tectonic Metal Cup Audio Exciter 19mm 3W 8 Ohm TEAX19C01-8

Tectonic 19 mm TEAX19C01-8 exciter continues their tradition of making magical devices (Distributed Mode Loudspeakers) that turn virtually any surface into a high fidelity loudspeaker. The exciter's small size enables audio reproduction in applications where installing conventional speakers just isn't possible, such as windows, monitors—even picture frames!

The TEAX19C01-8 exciter uses a neodymium magnet to increase magnetic flux around the voice coil. This results in increased sensitivity, which reduces power requirements and allows low power amplifiers to be used without sacrificing total output.

3M™ VHB™ tape is pre-installed on each exciter and offers unsurpassed surface adhesion while spreading the stress load across the entire length of the joint. This ensures maximum acoustic energy transfer between the transducer and the surface to which it is attached. Two terminals extend from the exciter for wire soldering purposes.

Note: an exciter's frequency response and sensitivity are completely dependent on the exciter's designated surface. Thinner, smaller materials will tend to be louder and facilitate mid/tweeter response. Thicker, larger materials will be slightly quieter but result in a more full-range sound.

Specifications: • Power handling: 3 watts RMS • VCdia: 19 mm • Nominal impedance: 8 ohms • Mounting ring: 0.875" dia.  • Dimensions: 1.56" dia. (including terminals), 1.31" dia. (without terminals) x 0.5" (12.8 mm) H • Weight: 29 grams.

Product Details

BrandTectonic
ModelTEAX19C01-8
Part Number297-208
UPC844632092558
Unit of MeasureEach
Weight0.09

Product Specifications

ApplicationFull-Range Exciter
Power Handling (RMS)3 Watts
Impedance8Ω
