Tang Band T2-2136SA Full Range Speaker Module 2-3/4" x 2-3/4"

Tang Band
Part #264-938

Tang Band T2-2136SA Full Range Speaker Module 2-3/4" x 2-3/4"

Tang Band
Part #264-938
Tang Band's T2-2136SA features a passive radiator-assisted 57 mm aluminum cone driver that plays from 80 to 20,000 Hz in a tiny 2.75" square package. Easily design ultra compact modern speakers never before thought possible.
Key Features
  • 57 mm aluminum cone driver with rubber damping and surround
  • Rear-mounted passive radiator extends system response to 80 Hz
  • Compact 2.75" square self-contained design, no additional enclosure needed
  • Just add an amplifier for high-quality, full-range sound!
Your Price: $54.98
+ FREE SHIPPING
MSRP: $70.99
Save $16.01 (23%)
Bulk Pricing
Quantity:Qty: 1-3 $54.98/ea
Quantity:Qty: 4+$52.23/ea
Order in the next 1 hr 47 min to ship today. Details

In Stock
Free Shipping available on orders over $49.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Tang Band T2-2136SA Full Range Speaker Module 2-3/4" x 2-3/4"

Tang Band's line of patented speaker modules are designed for modern audio applications such as sound bars, desktop multimedia speakers, flat panel TV speakers, and portable audio systems. Don't let Tang Band's diminutive driver modules fool you; each is built with a passive radiator that extends midbass frequency response, allowing these to mate to a subwoofer system quite easily.

The T2-2136SA speaker module is built around a passive radiator assisted, aluminum cone 57 mm inverted dome driver. This allows for a very full frequency response from a single, small driver. Advantages of this type of speaker design include the elimination of crossover components in the critical midrange, superb off-axis response due to the use of a small driver (without hot spots), and perfect time-alignment.

Note: Tang Band recommends the use of a 2nd order (-12 dB/octave) 60 Hz minimum high pass filter for the best possible sound. Higher power handling and output is possible by deploying multiple modules together.

Product Details

BrandTang Band
ModelT2-2136SA
Part Number264-938
UPC848864039275
Unit of MeasureEach
Weight0.4

Product Specifications

Nominal Diameter2"
Power Handling (RMS)10 Watts
Power Handling (MAX)20 Watts
Impedance4Ω
Frequency Response80 to 20,000Hz
Sensitivity80dB 2.83V/1m
Voice Coil Diameter1"

Materials of Construction

Cone MaterialAluminum
Surround MaterialRubber
Basket / Frame MaterialPolymer
Magnet MaterialFerrite

Mounting Information

Overall Outside DiameterSquare: 2.75"
Baffle Cutout Diameter2.25"
Depth2.23"
# Mounting Holes4
