  • Sure Electronics AA-AB32512 2x500W Class D Audio Amplifier Board Compact - T-Amp

CLEARANCE Sure Electronics AA-AB32512 2x500W Class D Audio Amplifier Board Compact - T-Amp

Sure ElectronicsPart # 320-3369
Model: AA-AB32512
Design your own powered subwoofer, powered speaker or audio amplifier with Sure's 2 x 500 watt stereo amp board. It's small in size, but ready to handle power demanding audio projects.

Key Features

  • Temperature controlled cooling fan
  • Over-engineered protection circuits
  • Versatile 3-ohm stability
  • Up to 1,000 watts max power
  • Requires 25 to 50 VDC power supply
  • Perfect size for use as a subwoofer amplifier for home or vehicle
  • 4-screw in standoffs for easy installation
Get Notified When Available

We'll send you an email when Sure Electronics AA-AB32512 2x500W Class D Audio Amplifier Board Compact - T-Amp is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Sure Electronics AA-AB32512 2x500W Class D Audio Amplifier Board Compact - T-Amp

This mid power stereo amplifier board means serious business! This audio amplifier board cranks out 1,000 watts of power using Sure Electronics T-AMP technology, featuring low distortion and low noise level. For do-it-yourselfers, looking for a audio amp for your home or vehicle.

Temperature controlled cooling fan, as well as protection circuits to protect against over/under voltage, over current, short circuit, and over temperature conditions are built-in for years of enjoyment. This amp board has three fixed gain setting or you can use Sure's plug in volume control option. A 25 to 50 VDC power supply is required.

Note: The minimum recommended wire gauge to be used for power is 16 AWG.

Specifications:
• Power output (w/ 48 VDC power supply): 250W x 2 (3 ohms, THD 10%), 130W x 2 (3 ohms, THD 1%)
• Minimum impedance: 3 ohms
• Frequency response: 20 to 20,000 Hz (±3 dB)
• SNR: 78.43 dB (260W @ 3? THD+N 1%)
• Recommended power supply: 25 to 50 VDC, 22.8A regulated
• Fixed gain settings: 28, 30, 32 dB
• Power input jack: 2.5 x 5.5 mm, center-positive
• Dimensions without RCA jack: 4.8" L x 3.6" W x 1.53" H

Product Details

BrandSure Electronics
ModelAA-AB32512
Part Number320-3369
UPC843577100717
Unit of MeasureEach
Weight0.85

Product Specifications

Board Type2 Channel Stereo Amp
Power (RMS/Channel 8 ohms)101 - 250 Watts
