  • Sure Electronics AA-AB31194 1x300W Class D Audio Amplifier Board - T-Amp

CLEARANCE Sure Electronics AA-AB31194 1x300W Class D Audio Amplifier Board - T-Amp

Sure ElectronicsPart # 320-3361
Model: AA-AB31194
Design your own powered subwoofer, powered speaker or subwoofer audio amplifier with Sure's 300 watt mono amp board. It's small in size, but ready to handle mid power demanding subwoofers or other active speaker projects.

Key Features

  • Perfect for use as a subwoofer amplifier for home or vehicle
  • Up to 300W of Class-D clean power
  • Versatile 2-ohm stability
  • Over-engineered protection circuits
  • Requires 15 to 42 VDC power supply
  • Temperature controlled cooling fan
  • 4-screw in standoffs for easy installation
Get Notified When Available

We'll send you an email when Sure Electronics AA-AB31194 1x300W Class D Audio Amplifier Board - T-Amp is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Sure Electronics AA-AB31194 1x300W Class D Audio Amplifier Board - T-Amp

This mid power mono amplifier board means serious business! This audio amplifier board cranks out 300 watts of power using Sure Electronics T-AMP technology, featuring low distortion and low noise level. For do-it-yourselfers, looking for a subwoofer amp for your home or vehicle.

Temperature controlled cooling fan, as well as protection circuits to protect against over/under voltage, over current, short circuit, and over temperature conditions are built-in for years of enjoyment. This amp board has a 28 dB fixed gain setting or you can use Sure's plug in volume control option. A 15 to 42 VDC power supply is required.

Note: The minimum recommended wire gauge to be used for power is 16 AWG.

Specifications:
• Power output (w/ 40 VDC power supply): 300W x 1 (3 ohms, THD 10%), 225W x 1 (3 ohms, THD 1%)
• Minimum impedance: 2 ohms
• Frequency response: 20 to 20,000 Hz (±3 dB)
• SNR: 96 dB (225W @ 3? THD+N 1%)
• Recommended power supply: 15 to 42 VDC, 8.5A regulated
• Fixed gain settings: 28 dB
• Power input jack: 2.5 x 5.5 mm, center-positive
• Dimensions without RCA jack: 4.8" L x 3.6" W x 1.5" H

Product Details

BrandSure Electronics
ModelAA-AB31194
Part Number320-3361
Unit of MeasureEach
Weight0.94

Product Specifications

Board Type1 Channel Mono Amp
Power (RMS/Channel 8 ohms)101 - 250 Watts
