  • Simply45 S45-1700 Pass Through RJ45 Connectors Red Tint for 23 AWG Cat6/6A UTP - 100pc Jar

CLEARANCE Simply45 S45-1700 Pass Through RJ45 Connectors Red Tint for 23 AWG Cat6/6A UTP - 100pc Jar

Simply45Part # 150-1012
Model: S45-1700
Simply45 is the industry-leading brand for RJ45 modular plug innovation and performance solutions. Simply45 S45-1700 23 AWG Cat6 UTP red tinted staggered pass-through RJ-45 connectors have three points for each terminal that ensure a connection every time after crimping with Simply45 ratcheting feed through crimpers.

Key Features

  • 3-prong pin design with 50µ of true 24ct gold plating for perfect connection every time
  • PoE/PoH rated for high current
  • Compliant with Industry standards ANSI/YIA568.2, 1096-A; ISO/IEC 11801, 60603-7, :1992; FCC8877
  • Red tint ensures your using the right connector for unshielded CAT6/6A solid 23 AWG LAN cables and stranded 23 AWG
  • UL94 V0 (IEC 60695-11-10) rated for commercial use and Plenum applications
  • Wires feed through the connector to make it easier to verify correct wiring sequence
  • Limited lifetime warranty from Simply45
Get Notified When Available

We'll send you an email when Simply45 S45-1700 Pass Through RJ45 Connectors Red Tint for 23 AWG Cat6/6A UTP - 100pc Jar is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Simply45 S45-1700 Pass Through RJ45 Connectors Red Tint for 23 AWG Cat6/6A UTP - 100pc Jar

Simply45 color coded connectors always insures you have the right connector for your various networking cables. If you have a handful of Simply45 unshielded connectors, how do you know what connectors go with CAT6 23 AWG cable. Look for the red tinted ones and you have your answer. The red lid on the jar also helps keep the colors identified and separated. The red tinted connectors work with wire conductors 1.00-1.10mm/0.039" - 0.043", Max cable OD 7.4mm (0.291").

All Simply45 true 24ct gold plated terminals make the perfect connection every time you crimp them with Simply45 ratchet action tools. All other RJ-45 connectors only have two pins per terminal that penetrate the wire jacket during the crimping cycle. If both of the spikes miss going through the jacket you have a bad connection, and you've just waisted a connector. Simply45 RJ-45 connectors have a three-pin design per terminal that guarantees that a pin will penetrate the jacket and make connection with the bare copper wire.

Simply45 RJ-45 connectors are compliant with industry standards and meet all the strict ratings for commercial applications. These RJ45 mod plugs are UL94 V0 (IEC 60695-11-10) rated for all commercial installations. These RJ45 mod plugs work perfect with CMP Plenum, CMR, CM; and LSZH up to B2ca rated LAN cables. They also meet ANSI/TIA 568.2-D, 1096-A; ISO/IEC 11801, 60603-7, 8877:1992; FCC industry standards. PoE/PoH rated for higher current applications.

Product Details

BrandSimply45
ModelS45-1700
Part Number150-1012
UPC817777016888
Unit of MeasurePackages
Weight0.4

Product Specifications

Cable TypeCategory 6A
