  • Pyle PDMR6 6-1/2" Sealed Back Midrange

Pyle PDMR6 6-1/2" Sealed Back Midrange

Pyle AudioPart # 292-208
Model: PDMR6
The sealed basket PDMR6 midrange does not require a separate enclosure, thereby simplifying custom installations.

Key Features

  • Sealed back design
  • Coated paper cone
  • 1'' high temperature voice coil
  • Polyimide VC former
  • 25 oz. magnet structure
  • Half-roll foam suspension
  • High efficiency
Your Price: $23.12
MSRP: $46.99
Save $23.87 (51%)
Bulk Pricing
Back-Ordered
Get Notified When Available

We'll send you an email when Pyle PDMR6 6-1/2" Sealed Back Midrange is back in stock or available for preorder.

Estimated back in stock 8/8/2025
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Pyle PDMR6 6-1/2" Sealed Back Midrange

Pyle Pro professional P.A. drivers provide high quality sound reproduction in a wide range of sizes and capabilities. The sealed basket PDMR6 midrange does not require a separate enclosure, thereby simplifying custom installations. Coated paper cone, 1" high temp voice coil, half-roll foam edge suspension.

Product Details

BrandPyle Audio
ModelPDMR6
Part Number292-208
UPC068888886789
Unit of MeasureEach
Weight3.5

Product Specifications

Nominal Diameter6-1/2"
Power Handling (RMS)150 Watts
Power Handling (MAX)300 Watts
Impedance8Ω
Frequency Response200 to 5,000Hz
Sensitivity93dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)321Hz
Mechanical Q (Qms)7.55
Electromagnetic Q (Qes)5.48
Total Q (Qts)3.18
Compliance Equivalent Volume (Vas)17.08ft³

Materials of Construction

Cone MaterialCoated Paper
Surround MaterialFoam

Mounting Information

Overall Outside Diameter6.54"
Baffle Cutout Diameter5.67"
Depth2.76"
# Mounting Holes4
