Peerless by Tymphany XXLS-P830845 12" Nomex Cone Subwoofer 8 Ohm

Peerless by TymphanyPart # 264-1646
Model: XXLS-P830845
4 Questions, 6 Answers or
This series of state-of-the-art subwoofers continues to enhance Peerless's reputation for delivering the highest quality components for bass.
Similar items that may interest you:
Dayton Audio RSS315HO-44 12" Reference Series HO DVC Subwoofer
Price: $249.98Part # 295-467
LaVoce SSF122.50L 12" Paper Cone Subwoofer
Price: $179.00Part # 293-788
See all items in Subwoofer Drivers
Your Price: $209.98
+ FREE SHIPPING
MSRP: $276.99
Save $67.01 (24%)
Bulk Pricing
In Stock
Get Notified When Available

We'll send you an email when Peerless by Tymphany XXLS-P830845 12" Nomex Cone Subwoofer 8 Ohm is back in stock or available for preorder.

Ships next business day. Details
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Peerless by Tymphany XXLS-P830845 12" Nomex Cone Subwoofer 8 Ohm

This series of state-of-the-art subwoofers continues to enhance Peerless's reputation for delivering the highest quality components for bass. Called the XXLS—for "Xpanded Extra Long Stroke"—these audio transducers add even more excursion to the Peerless XLS line while completely eliminating distortion. The XXLS line features a strong yet attractive cast frame, reinforced aluminum cone, flat spider, and generous under-spider venting. The magnet system incorporates multiple distortion-canceling fixtures.

Product Details

BrandPeerless by Tymphany
ModelXXLS-P830845
Part Number264-1646
UPC848864045900
Unit of MeasureEach
Weight15.05

Product Specifications

Nominal Diameter12"
Power Handling (RMS)175 Watts
Power Handling (MAX)350 Watts
Impedance8Ω
Sensitivity87.45dB 2.83V/1m
Voice Coil Diameter2.02"

Thiele-Small Parameters

Resonant Frequency (Fs)27.04Hz
DC Resistance (Re)5.66Ω
Voice Coil Inductance (Le)0.79mH
Mechanical Q (Qms)8.55
Electromagnetic Q (Qes)0.55
Total Q (Qts)0.52
Compliance Equivalent Volume (Vas)4.22ft³
Mechanical Compliance of Suspension (Cms)353mm/N
BL Product (BL)13.06T·m
Diaphragm Mass Inc. Airload (Mms)98.1g
Maximum Linear Excursion (Xmax)12.5mm
Surface Area of Cone (Sd)490.9cm²

Materials of Construction

Cone MaterialPaper
Surround MaterialRubber
Voice Coil Wire MaterialAluminum
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter12.12"
Baffle Cutout Diameter10.91"
Depth6.07"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume1.25ft³
Sealed F346.1Hz
Vented Volume3ft³
Vented F329.7Hz
