  • Peerless by Tymphany DFM-2535R00-08 1" Compression Horn Driver 2/4-Bolt 8 Ohm

CLEARANCE Peerless by Tymphany DFM-2535R00-08 1" Compression Horn Driver 2/4-Bolt 8 Ohm

Peerless by TymphanyPart # 264-1420
Model: DFM-2535R00-08
The Tymphany DFM-2535R00-08 1" exit compression driver features a titanium diaphragm with a polyimide surround. It delivers smooth, accurate high frequency response with an unusually low Fs for wide-range audio performance.

Key Features

  • Proprietary coating on titanium diaphragm promotes a detailed yet non-fatiguing high frequency response
  • 107.8 dB efficiency: high output relative to minimal input power
  • Smooth response from an exceptionally low 1,500 Hz all the way to 17,000 Hz
  • Polyimide surround provides durability and additional damping for natural sound quality
Get Notified When Available

We'll send you an email when Peerless by Tymphany DFM-2535R00-08 1" Compression Horn Driver 2/4-Bolt 8 Ohm is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Peerless by Tymphany DFM-2535R00-08 1" Compression Horn Driver 2/4-Bolt 8 Ohm

Peerless' first compression driver, the DFM-2535R00-08, delivers incredibly smooth response from 1,500 to 17,000 Hz thanks to its unique 1.4" damped titanium diaphragm with polyimide surround. This driver has a 1" exit with a standard 2 or 4-bolt mount. All of the materials resist environmental factors of heat, vibration, and aging, which ensures many years of stable performance. The Tymphany DFM-2535R00-08 HF driver is a great choice for use in pro-quality 2-way and 3-way sound reinforcement speaker systems, as well as high efficiency home and automotive audio playback applications.

Specifications: • Power handling: 30 watts RMS/60 watts program (with recommended 1,500 Hz, 12 dB/octave crossover) • Fs: 745 • VCdia: 1.4" • Throat diameter: 1" • Impedance: 8 ohms • Frequency response: 1,500-15,000 Hz • SPL: 107.7 dB 2.83V/1m • Dimensions: Overall diameter: 3.5", Depth: 2".

Product Details

BrandPeerless by Tymphany
ModelDFM-2535R00-08
Part Number264-1420
UPC848864017143
Unit of MeasureEach
Weight2.25

Product Specifications

Diaphragm MaterialTitanium
Exit Diameter1"
Mounting Type4-Bolt
Power Handling (RMS)30 Watts
Impedance8Ω
