  • Peerless by Tymphany D26NC05-06 1" Silk Dome Tweeter 6 Ohm

Peerless by Tymphany D26NC05-06 1" Silk Dome Tweeter 6 Ohm

Peerless by TymphanyPart # 264-1450
Model: D26NC05-06
With a surface mount housing, the Peerless D26NC05-06 is a simple addition to any car audio systems that can make a huge improvement. With a 1" silk dome and damped rear resonant chamber, this compact tweeter will produce smooth response with low distortion.

Key Features

  • Surface mount designs secures the driver while showing no fasteners
  • Integrated steel grill protects fragile dome from foreign objects
  • Neodymium motor for excellent dome control and high efficiency
  • Rear chamber and Ferrofluid cooling improves power handling
Similar items that may interest you:
Dayton Audio ND20FA-6 3/4" Soft Dome Neodymium Tweeter
Price: $10.98Part # 275-030
See all items in Tweeters
Get Notified When Available

We'll send you an email when Peerless by Tymphany D26NC05-06 1" Silk Dome Tweeter 6 Ohm is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

Peerless by Tymphany D26NC05-06 1" Silk Dome Tweeter 6 Ohm

The Peerless D26NC05-06 surface mount tweeter will provide smooth and accurate high frequency response thanks to the 1" silk dome and small rear resonant chamber. This tweeter is ideal for use in car audio systems, or even compact 2-way portable speaker designs.

Product Details

BrandPeerless by Tymphany
ModelD26NC05-06
Part Number264-1450
UPC848864045030
Unit of MeasureEach
Weight0.15

Product Specifications

Cone / Dome Diameter1"
Cutout Diametern/a
Tweeter TypeSoft Dome
Power Handling (RMS)30 Watts
Impedance
Frequency Response3,000 to 20,000Hz
Sensitivity87.4dB 2.83V/1m

Thiele-Small Parameters

Resonant Frequency (Fs)1579Hz
DC Resistance (Re)4.66Ω
Voice Coil Inductance (Le)0.02mH
Mechanical Q (Qms)1.11
Electromagnetic Q (Qes)2.61
Total Q (Qts)0.78

Mounting Information

Overall Outside Diameter1.77"
Depth0.86"
