Peerless by Tymphany ANC-50N25AL04-04 2" Full-Range Speaker 4 Ohm

2 Questions, 6 Answers or
Peerless by Tymphany
Part #264-1430

Peerless by Tymphany ANC-50N25AL04-04 2" Full-Range Speaker 4 Ohm

Peerless by Tymphany
Part #264-1430
Model: ANC-50N25AL04-04
2 Questions, 6 Answers or
The ANC-50N25AL04-04 2" full-range driver from Peerless produces smooth natural response and low distortion from 150 to 10,000 Hz. This driver features an aluminum cone, poly surround, and powerful neodymium motor.
Key Features
  • Compact size allows excellent off axis response
  • Aluminum cone with poly surround minimizes resonances
  • Flat mounting flange with gasket allows simple installation
  • Powerful neodymium motor reduces size and weight
Your Price: $13.79
MSRP: $18.99
Save $5.20 (27%)
Bulk Pricing

Back-Ordered

Advertised price subject to change due to tariff uncertainty
Alert Me When Available
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

Peerless by Tymphany ANC-50N25AL04-04 2" Full-Range Speaker 4 Ohm

Peerless by Tymphany ANC-50N25AL04-04 2" Full-Range Speaker 4 Ohm

The Peerless ANC-50N25AL04-04 2" 4 ohm full-range driver sets a high standard for compact full range drivers intended for use in telecommunications systems. It features an optimized motor and suspension for extremely low THD, a compact dome diaphragm for reduced depth and excellent radial acoustic dispersion, and an Aluminum dome for extended frequency response. This full range is a terrific choice for use in sound bars, Bluetooth speakers, and desktop systems.

Product Details

BrandPeerless by Tymphany
ModelANC-50N25AL04-04
Part Number264-1430
UPC848864044880
Unit of MeasureEach
Weight0.15

Product Specifications

Nominal Diameter2"
Bolt Circle Diameter0.12
Power Handling (RMS)5 Watts
Power Handling (MAX)10 Watts
Impedance4Ω
Frequency Response100 to 20,000Hz
Sensitivity82.9dB 2.83V/1m
Voice Coil Diameter1"

Thiele-Small Parameters

Resonant Frequency (Fs)132.63Hz
DC Resistance (Re)3.47Ω
Voice Coil Inductance (Le)0.06mH
Mechanical Q (Qms)2.06
Electromagnetic Q (Qes)0.48
Total Q (Qts)0.39
Compliance Equivalent Volume (Vas)0.01ft³
Mechanical Compliance of Suspension (Cms)1.13mm/N
BL Product (BL)2.78T·m
Diaphragm Mass Inc. Airload (Mms)1.3g
Maximum Linear Excursion (Xmax)1.8mm

Materials of Construction

Cone MaterialAluminum
Surround MaterialPolyurethane
Voice Coil FormerAluminum
Basket / Frame MaterialPolymer
Magnet MaterialNeodymium

Mounting Information

Overall Outside Diameter2.17"
Baffle Cutout Diameter1.92"
Depth0.76"
# Mounting Holes4

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.01ft³
Sealed F3285Hz
Vented Volume0.02ft³
Vented F3111.1Hz
