  • PRV Audio 18SW2200v2 18" Professional Subwoofer 8 Ohm

CLEARANCE PRV Audio 18SW2200v2 18" Professional Subwoofer 8 Ohm

PRV AudioPart # 294-2762
Model: 18SW2200v2
PRV Audio's 18" 18SW2200V2 subwoofer performs at many levels above its price point. 7 mm of Xmax, a 4" diameter voice coil, dual spider, and cotton M-Roll suspension all combine to form a subwoofer that remains linear at power levels up to 1,100 watts RMS!

Key Features

  • Amazing performance-to-price ratio and PRV Audio's most popular subwoofer series
  • High 1,100 watt RMS power handling and 7 mm of Xmax
  • Cast aluminum frame and spring-loaded terminals
  • Dual spider suspension and cotton M-Roll surround for driver linearity
  • 4" voice coil motor with extreme ventilation for minimum power compression
Similar items that may interest you:
Dayton Audio Pro 18 in. 8 Ohm Subwoofer Odeum 18F
Price: $224.98Part # 295-641
See all items in Pro Woofers, Subwoofers & Midrange Speakers
Get Notified When Available

We'll send you an email when PRV Audio 18SW2200v2 18" Professional Subwoofer 8 Ohm is back in stock or available for preorder.

60 Day No Hassle Return Policy

Overview

PRV Audio 18SW2200v2 18" Professional Subwoofer 8 Ohm

The 18SW2200V2 18" subwoofer is the newest version of the best selling professional audio loudspeakers in the PRV Audio subwoofer series. Its low frequency response and accuracy surprises listeners, not expecting this much performance from a subwoofer at this price point.

PRV Audio built the 18" 18SW2200V2 to play louder, and lower, by using a thoroughly vented, well executed motor. A 4" voice coil minimizes output-robbing power compression, while also increasing driver longevity and power handling. The use of a dual spider suspension, mated to a cotton M-Roll surround and ribbed cone (all attached with a special resin), allows for extreme linearity during intense use.

A reinforced cast aluminum frame increases rigidity and resists frame flex. Spring-loaded speaker terminals allow for easy speaker wire connection. This professional audio subwoofer is at home in bandpass or ported (bass reflex) speaker cabinets and has been used in live sound reinforcement, high SPL mobile audio systems, and as high output home theater systems.

Product Details

BrandPRV Audio
Model18SW2200v2
Part Number294-2762
UPC799928735384
Unit of MeasureEach
Weight32.95

Product Specifications

Nominal Diameter18"
Bolt Circle Diameter17.625
Power Handling (RMS)1100 Watts
Power Handling (MAX)2200 Watts
Impedance8Ω
Frequency Response45 to 2,500Hz
Sensitivity97dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)42.7Hz
DC Resistance (Re)5.1Ω
Voice Coil Inductance (Le)1.92mH
Mechanical Q (Qms)10.95
Electromagnetic Q (Qes)0.45
Total Q (Qts)0.44
Compliance Equivalent Volume (Vas)5.55ft³
Mechanical Compliance of Suspension (Cms)0.067mm/N
BL Product (BL)24.7T·m
Diaphragm Mass Inc. Airload (Mms)204.3g
Maximum Linear Excursion (Xmax)9.75mm
Surface Area of Cone (Sd)1288cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialFoam
Voice Coil Wire MaterialCopper
Voice Coil FormerFiberglass
Basket / Frame MaterialSteel
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter18.11"
Baffle Cutout Diameter16.65"
Depth8.07"
# Mounting Holes8

Parts Express Staff Recommended Enclosure Volume

Sealed Volume3.25ft³
Sealed F377.4Hz
Vented Volume6ft³
Vented F341Hz
