CLEARANCE PRV Audio 12SW6000BP-2 Brazilian Punch 12" Subwoofer Driver 2 Ohm

1 Question, 1 Answer or
PRV Audio
Part #294-3238

CLEARANCE PRV Audio 12SW6000BP-2 Brazilian Punch 12" Subwoofer Driver 2 Ohm

PRV Audio
Part #294-3238
Model: 12SW6000BP-2
1 Question, 1 Answer or

PRV Audio’s unique 12SW6000BP-2 Brazilian Punch 12” high efficiency 2 ohm subwoofer is built to deliver maximum impact and punch to open air designs, such as a stunt wall. This formidable driver features a huge 4” voice coil, stout cast aluminum frame, and massive double stacked motor. If you need head turning output with chest thumping bass response then the Brazilian Punch is the driver for you.

Key Features
  • 12-inch subwoofer with low midbass emphasis for impactful sound
  • Handles 3000 watts RMS and 6000 watts program power for high-output applications
  • 4-inch CCAW voice coil on a Kapton former for durability and heat dissipation
  • 92.5 dB sensitivity for efficient sound output with minimal power
  • Reinforced die-cast aluminum frame for long-lasting reliability
  • Optimized for ported enclosures in open-air environments
CLEARANCE $399.91
+ FREE SHIPPING
MSRP: $499.89
Save $99.98 (20%)
Bulk Pricing
Order in the next 2 hr 2 min to ship today. Details

Only 1 In Stock
Free Shipping available on orders over $99.00 in the US. Details
60 Day No Hassle Return Policy

Overview

PRV Audio 12SW6000BP-2 Brazilian Punch 12" Subwoofer Driver 2 Ohm

PRV Audio 12SW6000BP-2 Brazilian Punch 12" Subwoofer Driver 2 Ohm

The Brazilian Punch is an efficient woofer crafted for systems that require high performance in the low midbass range, delivering clean sound with impressive sound pressure levels.

This subwoofer is far from an ordinary subwoofer—it’s specifically designed to produce low-mid frequencies in ported enclosures for open-air setups like stunt walls. The Brazilian Punch is inspired by the "pancadão" sound system style that originated in Brazil, meaning "strong beat" in Portuguese.

PRV recommends building a stunt wall with 8 or more of this speaker. With the recommended box and crossover filter, you're sure to be the talk of the car show! The high level of sound pressure will be felt from feet away.

Product Details

BrandPRV Audio
Model12SW6000BP-2
Part Number294-3238
UPC619620088246
Unit of MeasureEach
Weight45.2

Product Specifications

Nominal Diameter12"
Power Handling (RMS)3000 Watts
Power Handling (MAX)6000 Watts
Impedance2Ω
Frequency Response75 to 2,500Hz
Sensitivity99dB 2.83V/1m
Voice Coil Diameter4"

Thiele-Small Parameters

Resonant Frequency (Fs)81.8Hz
DC Resistance (Re)1.5Ω
Voice Coil Inductance (Le)0.38mH
Mechanical Q (Qms)5.44
Electromagnetic Q (Qes)0.51
Total Q (Qts)0.47
Compliance Equivalent Volume (Vas)0.325ft³
Mechanical Compliance of Suspension (Cms)0.023mm/N
BL Product (BL)15.57T·m
Diaphragm Mass Inc. Airload (Mms)161.9g
Maximum Linear Excursion (Xmax)10.75mm
Surface Area of Cone (Sd)526.4cm²

Materials of Construction

Cone MaterialTreated Paper
Surround MaterialCloth
Voice Coil Wire MaterialCCA
Voice Coil FormerKapton® / Polyimide
Basket / Frame MaterialCast Aluminum
Magnet MaterialFerrite

Mounting Information

Overall Outside Diameter12.56"
Baffle Cutout Diameter11.25"
Depth7.36"
# Mounting Holes6

Parts Express Staff Recommended Enclosure Volume

Sealed Volume0.75ft³
Sealed F3145Hz
Vented Volume1.25ft³
Vented F367.7Hz
